Image Sensor
|
1/3” Progressive Scan CMOS |
Min.Illumination
|
0.07Lux @F1.2, AGC ON, 0 lux with IR |
Shutter Time
|
1/3s ~ 1/100,100s |
Lens
|
4mm @ F2.0, (2.8mm, 6mm optional) Angle of view: 98.5°(2.8mm), 79°(4mm), 49°(6mm) |
Lens Mount
|
M12 |
Angle Adjustment
|
Pan: 0° ~ 355°, Tilt: 0° ~ 65°, Rotation: 0 ~ 360° |
Digital Noise Reduction
|
3D DNR |
Wide Dynamic Range
|
Digital WDR |
Day/Night
|
IR cut filter with auto switch |
Video Compression
|
H.264 / MJPEG |
H.264 codec profile
|
Main profile |
Bit rate
|
32 Kbps ~ 16 Mbps |
Dual Stream
|
Yes |
Max. Image Resolution
|
1920 x 1080 |
Frame Rate
|
50Hz: 25fps (1920 × 1080), 25fps (1280 x 720) 60Hz: 30fps (1920 × 1080), 30fps (1280 x 720) |
Image settings
|
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
BLC
|
Yes, zone configurable |
ROI
|
Yes, up to 3 configurable areas |
Network storage
|
Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB ; NAS |
Alarm Triggers
|
Intrusion detection, Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage full, Storage error |
Protocol
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
System compatibility
|
ONVIF, PSIA, CGI, ISAPI |
General functionalities
|
User Authentication, Watermark |
General function
|
Flickerless, dual stream, heartbeat, mirror, password protection, watermark |
Communication interface
|
1 RJ45 10M/100M Ethernet interface |
Communication interface
|
IEEE802.11b, 802.11g, 802.11n Draf |
Frequency
|
2.4 GHz ~ 2.4835 GHz |
Channels
|
20/40MHz Support |
Protocol
|
802.11b: CCK, QPSK, BPSK ; 802.11g/n: OFDM |
Security
|
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmit Output Power
|
11b: 17±1.5dBm @ 11Mbps ; 11g: 14±1.5dBm @ 54Mbps ; 11n: 12.5±1.5dBm |
Receive Sensitivity
|
11b: -90dBm @ 11Mbps (Typical) ; 11g: -75dBm @ 54Mpbs (Typical) ; 11n: -74dBm (Typical) |
Transfer Rates
|
11b: 11Mbps ; 11g: 54Mbps ; 11n: up to 150Mbps |
Wireless Range
|
Outdoor: 200m, Indoor: 50m ; *The performance varies based on actual environment. |
Operating Conditions
|
-30 °C ~ 60 °C (-22 °F ~ 140 °F) ; Humidity 95% or less (non-condensing) |
Power Supply
|
12 V DC ± 10% ; PoE (802.3af ) |
Power Consumption (±10%)
|
Max. 5 W (Max. 7 W with IR cut filter on) |
Impact protection
|
IEC60068-2-75Eh, 20J; EN50102, up to IK10 -W: En50102, up to IK8 |
Ingress Protection
|
IP66 |
IR Range
|
30 meters |
Dimension
|
Φ111 × 82 (4.4” × 3.2”) |
Weight
|
500g (1.1 lbs) |
