Image Sensor
|
1/3" Progressive Scan CMOS |
|
Min.Illumination
|
0.5 lux@F1.2, AGC on, 0.1 lux@F1.2, AGC on, sens-up × 5 1.1 lux@F1.8, AGC on, 0.2 lux@F1.8, AGC on, sens-up × 5 |
|
Shutter Time
|
1/25s ~1/100,000s |
|
Lens
|
4 mm @F1.8 Angle of view: 71° |
|
Lens Mount
|
M12 |
|
Day/Night
|
Electronic |
|
Video Compression
|
H.264 / MPEG4 / MJPEG |
|
Bit rate
|
32 Kbps ~ 16 Mbps |
|
Audio Compression
|
G.711/G.726 |
|
Dual Stream
|
Yes |
|
Max. Image Resolution
|
1600x1200 |
|
Frame Rate
|
50 Hz: 12.5 fps (1600 × 1200) 12.5 fps (1600 × 912) 25 fps (1280 × 960) 25 fps (1280 × 720) 60 Hz: 15 fps (1600 × 1200) 15 fps (1600 × 912) 25 fps (1280 × 960) 30 fps (1280 × 720) |
|
Image settings
|
Saturation, brightness, contrast adjustable through client software or web browser |
|
Network storage
|
NAS (iSCSI optional) |
|
Alarm Triggers
|
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
|
Protocol
|
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP,802.1x, Qos (SIP, SRTP, IPv6 optional) |
|
Security
|
User authentication, watermark |
|
System compatibility
|
ONVIF, PSIA, CGI |
|
Audio
|
Internal Microphone and Speaker |
|
Communication interface
|
1 RJ45 10M / 100M ethernet interface |
|
Onboard storage
|
Built-in Micro SD slot, up to 32 GB |
|
Reset Button
|
Yes |
|
Operating Conditions
|
-10 °C ~ 60 °C (14 °F ~ 140 °F) Humidity 90% or less (non-condensing) |
|
Power Supply
|
5 V DC ± 10% /PoE (802.3af) |
|
Power Consumption
|
4W MAX |
|
Dimension
|
70.4 × 110 × 47.6mm (2.77" × 4.33" × 1.87") |
|
Weight
|
250g (0.55 lbs) |
