Image Sensor
|
1/3" Progressive Scan CMOS |
|
Min.Illumination
|
0.5 lux@F1.2, AGC on, 0.1 lux@F1.2, AGC on, sens-up × 5 -I: 0.5 lux@F1.2, AGC on, 0.1 lux@F1.2, AGC on, sens-up × 5 0 lux with IR |
|
Shutter Time
|
1/25s~1/100,000s |
|
Lens
|
2.7 ~ 9 mm @F1.2 Angle of view: 101° ~ 30.4° -Z: motorized VF lens |
|
Lens Mount
|
φ14 |
|
Auto-iris
|
DC drive |
|
Adjustment Range
|
Pan: 0° ~ 360°, tilt: 0° ~ 75°, rotation: 0°~ 360° |
|
Day/Night
|
Electronic (-I: IR cut filter with auto switch) |
|
Video Compression
|
H.264 / MPEG4 / MJPEG |
|
Bit rate
|
32 Kbps ~ 16 Mbps |
|
Audio Compression
|
G.711/G.726 |
|
Dual Stream
|
Yes |
|
Max. Image Resolution
|
1600x1200 |
|
Frame Rate
|
50HZ: 12.5fps (1600×1200), 12.5fps (1600×912), 25fps (1280×960), 25fps (1280×720) 60HZ: 15fps (1600×1200), 15fps (1600×912), 25fps (1280×960), 30fps (1280×720) |
|
Image settings
|
Saturation, brightness, contrast adjustable through client software or web browser |
|
Network storage
|
NAS (iSCSI optional) |
|
Alarm Triggers
|
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
|
Alarm Triggers
|
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP,802.1x, Qos (SIP, SRTP, IPv6 optional) |
|
Security
|
User authentication, watermark |
|
System compatibility
|
ONVIF, PSIA, CGI |
|
Audio Input
|
1-ch 3.5 mm audio interface, MIC IN/LINE IN |
|
Audio Output
|
1-ch 3.5mm audio interface (line level, 600 Ω) |
|
Communication interface
|
1 RJ45 10M / 100M ethernet interface and 1 RS-485 interface |
|
Alarm in
|
2 |
|
Alarm out
|
2 |
|
Video Output
|
1Vp-p Composite Output(75Ohm, RCA) |
|
On Board Storage
|
Built-in SD/SDHC slot, up to 32 GB |
|
Reset Button
|
Yes |
|
Operating Conditions
|
10 °C ~ 60 °C (14 °F ~ 140 °F) Humidity 90% or less (non-condensing) |
|
Power Supply
|
12 VDC ± 10%, PoE (802.3af) |
|
Power Consumption
|
4.5 W ~ 9.5 W (IR LEDs: +2W, motorized VF lens: +3W) |
|
Impact protection
|
IEC60068-2-75Eh, 50J; EN50102, up to IK10 |
|
IR Range
|
-I: Approx 10 to 20 meters (32.8-65.6ft) |
|
Dimension
|
Φ140mm×114mm (Φ5.51"×4.49") |
|
Dimension
|
1400g (3.09 lbs) |
