| Camera |
| Image Sensor: |
1/3” DIS |
| Signal System: |
PAL/NTSC |
| Effective Pixels: |
720(H)×480(V) |
| Min. Illumination: |
0.1Lux @ (F1.2,AGC ON),0 Lux with IR
0.14Lux @ (F1.4,AGC ON),0 Lux with IR |
| Shutter Time: |
1/25(1/30) s to 1/15,000 s |
| Lens: |
2.8-12 mm @ F1.4
Angle of view: 92° - 27.2° |
| Lens Mount: |
φ14 |
| Adjustment Range: |
Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day& Night: |
IR cut filter with auto switch |
| Horizontal Resolution: |
600TVL |
| Synchronization: |
Internal Synchronization |
| Video Output: |
1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: |
More than 52dB |
| BLC: |
On |
|
