Specifications
|
| Image Sensor |
1/3” 1.3Megapixel PS CCD |
| Minimum Illumination |
0. 2LUX/F1.2 (Color), 0.01LUX/F1.2(B/W) |
| Shutter Speed |
Auto/Manual,1/50~1/10000s |
| White Balance |
Auto |
| AGC control |
Auto/Manual |
| Back Light Comp. |
BLC |
| S/N Ratio |
more than 50 dB |
| Video Compression |
H.264/MJPEG |
| Resolution |
1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288) |
| Video Output |
1 channel BNC(1.0Vp-p, 75Ω) |
| Video Streaming |
Main Stream: 1.3M(1~12fps)/720P(1 ~ 25fps), Sub Stream: D1/CIF(1 ~ 25/30fps) |
| ICR |
Auto(ICR) / Color / B/W |
| Lens |
C/CS Mount Lens |
| Privacy Masking |
Up to 4 areas |
| Interface |
RJ-45 (10/100Base-T), 1 RS485 |
| Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0 |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Operating Temperature |
-10°C~+60°C, 10%~90% |
| Power Source |
DC12V/AC24V, PoE(802.3af) |
| Power Consumption |
<7W |
| Regulatory |
CE, FCC and RoHS |
| Dimension |
70mm×149.5mm×63.2mm |
| Weight |
650g |
| Micro SD |
Max 32GB |
| User Account |
10 users |
| Alarm IN |
1 Ch. |
| Alarm Out |
1 Ch. |
| Audio Input |
1 channel |
| Audio Output |
1 channel |
| Audio Compression |
G.711a / G.711u(64kbps)/PCM(128kbps) |
