Specifications
|
| Image Sensor |
1/3” 2Megapixel Exmor CMOS |
| Minimum Illumination |
0. 2LUX/F1.2 |
| Shutter Speed |
Auto/Manual, 1/3~1/10000s |
| White Balance |
Auto |
| AGC control |
Auto/Manual |
| Back Light Comp. |
BLC / HLC / DWDR |
| S/N Ratio |
more than 50 dB |
| Video Compression |
H.264/MJPEG |
| Resolution |
1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) |
| Video Output |
1 channel BNC(1.0Vp-p, 75Ω) |
| Video Streaming |
Main Stream: 1080P/720P(1 ~ 25/30fps), Sub Stream: D1/CIF(1 ~ 25/30fps) |
| ICR |
Auto(ICR) / Color / B/W |
| Lens |
C/CS Mount Lens |
| Privacy Masking |
Up to 4 areas |
| Interface |
RJ-45 (10/100Base-T), RS232 & RS485 |
| Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0 |
| Snapshot |
Fastest 1fps JPEG capture |
| Operating Temperature |
-10°C~+60°C, 10%~90% |
| Power Source |
DC12V/AC24V, PoE(802.3af) |
| Power Consumption |
Max 6W |
| Regulatory |
CE, FCC and RoHS |
| Dimension |
70mm×149.5mm×63.2mm |
| Weight |
650g |
| Micro SD |
Max 32GB |
| User Account |
10 users |
| Alarm IN |
1 Input |
| Alarm Out |
1 Output |
| Audio Input |
1 channel |
| Audio Output |
1 channel |
| Audio Compression |
G.711a / G.711u(64kbps)/PCM(128kbps) |
| Auto Iris |
Supported |
