Specifications
|
| Processor |
High performance embedded microprocessor |
| Operating System |
Embedded LINUX |
| System Resources |
Pentaplex function: live, recording, playback, backup & remote access |
| User Interface |
GUI |
| Video Input |
16 Ch., BNC |
| Video Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
| Compression |
H.264 |
| Video Compression |
H.264 CIF Realtime DVR |
| Video Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
| Video Recording |
CIF (1~25/30fps) |
| Video Display Split |
1/4/8/9/16 |
| Privacy Masking |
4 rectangular zones (each camera) |
| Audio Input |
1 channel, RCA |
| Audio Output |
1 channel, RCA |
| Motion Detection |
supports |
| Video Loss |
supports |
| Hard Disk |
1 SATA port, up to 4TB |
| HDD Management |
Hard disk hibernation technology, HDD faulty alarm & Raid(Redundancy) |
| Recording Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Playback |
16 Ch |
| Backup Mode |
USB Device / Network |
| Interface Ports |
1 RS485, 2 USB2.0, 1 RJ45 |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Protocols |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server |
| Power Supply |
DC12V / 2A |
| Power Consumption |
10W(without HDD) |
| Working Temp |
-10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimensions |
325mm×240mm×45mm |
| Weight |
1.5KG(without HDD) |
| Alarm Input |
16 channel |
| Alarm Output |
1 channel |
