Imaging Device
|
1/2.8" PS Exmor 2.38M CMOS |
Total Pixels
|
1,952(H) x 1,116(V) |
Effective Pixels
|
1,944(H) x 1,104(V) |
Scanning System
|
Progressive scan |
Min.Illumination
|
Color : 0.1Lux (1/30sec, F1.2, 50IRE), 0.0017Lux (2sec, F1.2, 50IRE), B/W : 0Lux (IR LED on) |
S/N RATIO
|
50dB |
Video Output
|
CVBS : 1.0 Vpp / 75 Ω composite, 704 x 480(N), 704 x 576(P), for installation, DIP connector type |
Focal Lenght (Zoom Ratio)
|
3 ~ 8.5mm (2.8x) motorized varifocal |
Max. Aperture Ratio
|
F1.2 |
Angular Field of View
|
H : 105.5°(Wide) ~ 37.1°(Tele) / V : 57.5°(Wide) ~ 21.0°(Tele) |
Min. Object Distance
|
0.5m (1.64ft) |
Focus Control
|
Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus, Day & Night) |
Lens Type
|
Manual / DC auto iris |
Mount Type
|
Board type |
IR LED
|
20 units |
Viewable Length
|
30m (98.43ft) |
Camera Title
|
Off / On (Displayed up to 45 characters) |
Day/Night
|
Auto (ICR) / Color / B/W / External / Schedule |
Backlight Compensation
|
Off / BLC |
Wide Dynamic Range
|
100dB |
Contrast Enhancement
|
SSDR (Off / On) |
Noise Reduction
|
SSNR III (2D+3D noise filter) (Off / On) |
Digital Image Stabilization
|
Off / On |
Defog
|
Off / Auto / Manual |
Motion Detection
|
Off / On (4ea 4 points polygonal zones) |
Privasi masking
|
Off / On (32 zones with 4 points of polygonal) |
Gain Control
|
Low / Middle / High / Off |
White Balance
|
ATW / Outdoor / Indoor / Manual / AWC |
Electronic Shutter
|
Minimum / Maximum / Anti flicker |
Flip / Mirror
|
Off / On |
Intelligent Video Analytics
|
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection |
Alarm I/O
|
Input 1ea / Output 1ea |
Alarm Triggers
|
Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input |
Alarm Events
|
File upload via FTP and E-mail, Notification via E-mail, TCP, Local storage (SD/SDHC/SDXC) recording at Network disconnected & Event (Alarm triggers), External output |
Ethernet
|
RJ-45 (10/100BASE-T) |
Video Compression
|
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution
|
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Max. Framerate
|
H.264 : Max. 60fps at all resolutions MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max.30fps |
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
Bitrate Control
|
H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability
|
Multiple streaming (Up to 10 profiles) |
Audio Input
|
Selectable (Mic in / Line in), Max output level : 1 Vrms Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
Audio Output
|
Line out (3.5mm stereo mini jack) |
Audio Compression
|
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Audio Communication
|
Bi-directional audio |
IP
|
IPv4, IPv6 |
Protocol Support
|
CP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
Streaming Method
|
Unicast / Multicast |
Max. User Access
|
15 users at unicast mode |
Memory Slot
|
Micro SD/SDHC/SDXC Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded |
Application Programming Interface
|
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
Webpage Language
|
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
Web Viewer
|
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11, 10, 9, 8), Mozilla Firefox (Ver. 19, 18, 17, 16, 15, 14, 13, 12, 11, 10, 9), Google Chrome (Ver. 25, 24, 23, 22, 21, 20, 19, 18, 17,16, 15), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
Central Management Software
|
SmartViewer 4.0 |
Operating Temperature
|
24V AC : -50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH 12V DC, PoE : -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Storage Temperature
|
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
Ingress Protection
|
IP66 |
Vandal Resistance
|
IK10 |
Input Voltage / Current
|
12V DC, 24V AC, PoE (IEEE802.3af) |
Power Consumption (±10%)
|
Max. 11W (Heater off), Max. 17W (24V AC - Heater on) |
Color / Material
|
Dark gray / Metal |
Dimensions (mm)
|
90.4 x 96.0 x 333.2mm (3.56" x 3.78" x 13.12") |
Weight
|
1.19Kg (2.62 lb) |
