| VIDEO |
|
| Imaging Device |
1/1.7" 12.4M CMOS |
| Total Pixels / Effective Pixels |
4,168(H) x 3,062(V) / 4,072(H) x 3,046(V) |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.3Lux (1/30sec, F1.6, 30IRE), 0.01Lux (2sec, F1.6, 30IRE)
B/W : 0Lux (IR LED on) |
| S / N Ratio |
50dB |
| Video output |
CVBS : 1.0 Vpp / 75Ω composite, 702 x 576, for installation DIP connector type |
| LENS |
|
| Focal Length (Zoom Ratio) |
4.5 ~ 10mm (2.2x) motorized varifocal |
| Max. Aperture Ratio |
F1.6 |
| Angular Field of View |
[4096 x 2160] H : 100.3°(Wide) ~ 45.6°(Tele) / V : 49.7°(Wide) ~ 24.0°(Tele)
[3840 x 2160] H : 92.3°(Wide) ~ 42.6°(Tele) / V : 49.7°(Wide) ~ 24.0°(Tele) |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
| Lens Type / Mount Type |
P-Iris mode / Board-in type |
| OPERATIONAL |
|
| Viewable Length |
40m (131.23ft) |
| Camera Title |
Off / On (Displayed up to 60 characters)
- W/W : English / Numeric / Special characters
- China : English / Numeric / Special / Chinese characters
- Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White), Transparency, Auto
scale by resolution |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC / WDR |
| Wide Dynamic Range |
120dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNR (2D+3D noise filter) (Off / On) |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (8ea, Polygonal) |
| Privacy Masking |
Off / On (16ea, Polygonal) - Color : Gray / Green / Red / Blue / Black / White |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (Include mercury & sodium) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Flip / Mirror |
Off / On, Hallway : 90° /270° |
| Intelligent Video Analytics |
Tampering (Scene change), Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Defocus detection, Digital auto tracking - with metadata |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Alarm input, Motion detection, Video analytics, Audio detection, Network disconnect |
| Alarm Events |
File upload via FTP and E-mail, Notification via E-mail Local storage (SD/SDHC/SDXC) or NAS recording
at event triggers, External output |
| Pixel Counter |
Support (Plug-in viewer only) |
| NETWORK |
|
| Ethernet |
RJ-45 (10/100/1000BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG |
| Resolution |
[8M mode] 4096 x 2160, 3840 x 2160, 2592 x 1944, 2592 x 1464, 1920 x 1080, 1600 x 1200,
1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480,
640 x 480, 640 x 360, 320 x 240 [12M mode] 4000 x 3000, 3840 x 2160, 2592 x 1944, 2592 x 1464, 1920 x
1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720
x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265 / H.264 : 20fps@4000 x 3000, 30fps@4096 x 2160
MJPEG : 2fps@4000 x 3000 ~ 2592 x 1464, 15fps@1920 x 1080 ~ 320 x 240 |
| Smart Codec / WiseStream |
Manual mode (Area-based : 5ea) / Support |
| Video Quality Adjustment |
H.265 / H.264 : Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 3 profiles) |
| Audio In |
Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio out |
Line out (3.5mm mono jack), Max output level : 1Vrms |
| Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz |
| Audio Communication |
Bi-directional audio (2-way) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log,
802.1x authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
15 users at unicast mode |
| Edge Storage |
SD/SDHC/SDXC (128GB) - Motion images recorded in the SD/SDHC/SDXC memory card can be
downloaded, Camera can detect automatically when the memory is connected, Memory status
display (Normal / Error / Active / Formatting / Lock), NAS (Network Attached Storage), Local PC for
instant recording (Plug-in viewer only) |
| Application Programming Interface |
ONVIF profile S/G, SUNAPI (HTTP API), SVNP, Wisenet Open Platform |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Russian, Japanese, Swedish, Portuguese, Turkish,
Polish, Czech, Dutch, Hungary, Greek |
| Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.9, 10.10, 10.11
Plug-in free Webviewer
- Supported Browser : Google Chrome 47, MS Edge 20
Plug-in Webviewer
- Supported Browser : MS Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X only |
| Central Management Software |
SmartViewer |
| ENVIRONMENTAL |
|
| operating Temperature / Humidity |
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH * Start up should be done at above -35°C (-31°F) |
| Storage Temperature / Humidity |
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH |
| Ingress Protection / Vandal Resistance |
IP66 / IK10 |
| ELECTRICAL |
|
| Input Voltage / Current |
24V AC, 12V DC, PoE (IEEE802.3af, Class3) |
| Power Consumption |
12V DC : Max. 11.55W, PoE : Max.12.95W, 24V AC (50/60Hz) : 14.08W - Heater on12V DC : Max. 10.45W,
PoE : Max.11.77W, 24V AC (50/60Hz) : 12.43W - Heater off |
| MECHANICAL |
|
| Color / Material |
Dark gray / Aluminium |
| Dimensions (WxHxD) |
82.4 x 87.0 x 348.3mm (3.24" x 3.43" x 13.71") (Without sunshield) |
| Weight |
1.4Kg (3.09 lb) |
