Image Sensor
|
1/3’’ CMOS Sensor |
Max. Image Resolution
|
1280 x 720 |
Signal System
|
PAL / NTSC |
Min.Illumination
|
Color: 0.02Lux@( F1.6,AGC ON) ; B / W: 0.002Lux@( F1.6,AGC ON), 0 Lux with IR |
White Balance
|
Auto / Manual / ATW / Indoor / Outdoor |
AGC
|
Auto / Manual |
S/N Ratio
|
≥50dB |
3D DNR
|
Support |
Digital WDR
|
Support |
EIS
|
Support |
Backlight Compensation
|
Support |
Shutter Time
|
PAL: 1-1 / 10,000s ; NTSC: 1-1 / 10,000s |
Day/Night
|
IR Cut Filter |
Digital Zoom
|
16x |
Privasi masking
|
8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen |
Focus mode
|
Auto / Semiautomatic / Manual |
Focal length
|
4-92mm, 23X |
Zoom Speed
|
Approx.4.0s(Optical Wide-Tele) |
Angle of View
|
49-2.2 degree(Wide-Tele) |
Min. working distance
|
10-1000mm (Wide-Tele) |
Aperture range
|
F1.6-F3.7 |
Pan Range
|
360° endless |
Pan Speed
|
Pan Manual Speed: 0.1°-160° / s; Pan Preset Speed: 240° / s |
Tilt Range
|
-15°-90° (Auto Flip ) |
Tilt Speed
|
Tilt Manual Speed: 0.1°-120° / s; Tilt Preset Speed: 200° / s |
Proportional zoom
|
Rotation speed can be adjusted automatically according to zoom multiples |
Number of preset
|
256 |
Patrol
|
8 patrols, up to 32 presets per patrol |
Pattern
|
4 patterns, with the total recording time not less than 10 minutes |
Power-off memory
|
Support |
Park action
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan |
PTZ position display
|
On / Of |
Preset freezing
|
Support |
Scheduled task
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan |
RS485 Port
|
Support |
IR distance
|
120m |
IR intensity
|
Automatically adjusted, depending on the zoom ratio |
Monitor Output
|
HD 720P output, 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC |
RS-485 Interface
|
Half-duplex mode; Self-adaptive HIKVISION, Pelco-P, Pelco-D protocol |
UTC Function
|
Support |
Language
|
English, Chinese |
