Image Sensor
|
1/3" Progressive Scan CMOS |
Effective Pixels
|
1920(H)x1080(V) |
Signal System
|
PAL/NTSC |
Min.Illumination
|
Color: 0.02Lux@(F1.6,AGC ON) B/W: 0.002Lux@(F1.6,AGC ON) 0 lux with IR |
White Balance
|
Auto / Manual / ATW / Indoor / Outdoor |
AGC
|
Auto/Manual |
S/N Ratio
|
≥ 50dB |
BLC
|
ON/OFF |
WDR
|
Support |
Shutter Time
|
PAL: 1-1/10,000s NTSC: 1-1/10,000s |
Day/Night
|
ICR |
Digital Zoom
|
16x |
Privasi masking
|
8 privacy masks programmable |
Auto Focus:
|
Auto / Semi-automatic / Manual |
Focal length
|
4-120mm, 30X |
Zoom Speed
|
Approx.3.0s(Optical Wide-Tele) |
Angle of View
|
58-21.7 degree(Wide-Tele) |
Min. working distance
|
10-1500mm (Wide-Tele) |
Aperture range
|
F1.6-F4.4 |
Pan Range
|
360°endless |
Pan Speed
|
Pan Manual Speed: 0.1°-160°/s, Pan Preset Speed: 240°/s |
Tilt Range
|
-15°-90° (Auto Flip ) |
Tilt Speed
|
Tilt Manual Speed: 0.1°-120°/s, Tilt Preset Speed: 200°/s |
Proportional zoom
|
Rotation speed can be adjusted automatically according to zoom multiples |
Number of preset
|
256 |
Patrol
|
8 patrols, up to 32 presets per patrol |
Pattern
|
4 patterns, with the total recording time not less than 10 minutes |
Power loss recovery
|
Support |
Park action
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
PTZ position display
|
ON/OFF |
IR irradiation distance
|
120m |
IR irradiation angle
|
Adjustable by zoom |
RS-485 Protocol
|
Pelco-P, Pelco-D, self-adaptive |
Language
|
English / Chinese |
Power Supply
|
24V AC |
Power Consumption (±10%)
|
Max. 30W(IR: 9W, Heater: 6W) |
Working Temperature/Humidity
|
-30 °C-65°C(-22°F-149°F) 90% or less |
Protection level
|
IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
Dimension
|
Φ220×353.4mm (Φ8.66”×13.91”) |
Weight (approx.)
|
4.5kg(9.92 Ibs) |
Mount option
|
Long-arm wall mount: DS-1602ZJ;Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box |
