| Video/Audio Input |
| Video Compression: |
H.264 |
| Analog Video Input: |
8-ch |
| PAL/NTSC Adaptive: |
Support |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
G.711 |
| Audio Input: |
1-ch |
| Audio Input Interface: |
RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: |
1-ch RCA(2.0Vp-p, 1kΩ) |
|
| Video/Audio Output |
| VGA Output: |
1-ch, resolution: 1280×1024/60Hz, 1024×768/60Hz |
| CVBS Output: |
1-ch, BNC connector (1.0 Vp-p, 75 Ω);
Resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Recording resolution: |
4CIF/2CIF/CIF |
| Frame Rate: |
Main stream: 4CIF / 2CIF @ 8 fps
Sub stream: CIF / QCIF |
| Video Bit Rate: |
32Kbps~2048Kbps, or user-defined (Max.3Mbps) |
| Stream Type: |
Video/Video&Audio |
| Audio Output: |
1-ch RCA(Linear, 1kΩ) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Support |
| Synchronous Playback: |
8-ch |
|
| Hard Disk Driver |
| Interface Type: |
1 SATA Interface |
| Capacity: |
Up to 2TB capacity for each disk |
|
| External Interface |
| Network Interface: |
1 RJ45 10M/100M adaptive Ethernet Interface |
| USB Interface: |
2 USB 2.0 Interfaces |
| Serial Interface: |
1 RS-485 interface |
|
| General |
| Power Supply: |
12 VDC |
| Consumption: |
≤10W (without hard disk
or DVD-R/W) |
| Working Temperature: |
-10 °C ~ +55 °C |
| Working Humidity: |
10% ~ 90% |
| Chassis: |
Standalone 1U chassis |
| Dimensions: |
315 (W)× 230(D) × 45 (H)mm |
| Weight: |
≤ 2kg (without hard disk
or DVD-R/W) |
|
