- Image Sensor
1/3” 1.3Megapixel PS CCD
- Minimum Illumination
0.2lux/F1.4(color),0.01Lux/F1.4(B/W),0Lux(IR on)
- Shutter Speed
Auto/Manual,1/50~1/10000s
- White Balance
Auto
- AGC control
Auto/Manual
- Back Light Comp.
BLC
- Lens
2.8~12mm
- S/N Ratio
more than 50 dB
- Video Compression
H.264/MJPEG
- Video Streaming
Main Stream: 1.3M(1~12fps)/720P(1 ~ 25fps), Sub Stream: D1/CIF(1 ~ 25/30fps)
- Resolution
1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
- Video Output
1 channel BNC(1.0Vp-p, 75Ω)
- Privacy Masking
Up to 4 areas
- ICR
Auto(ICR) / Color / B/W
- Smart Phone
iPhone, iPad, Android, Windows Phone
- Audio Input
1 Channel
- Audio Output
1 Channel
- Audio Compression
G.711a / G.711u(64kbps) / PCM(128kbps)
- Alarm IN
2 Channel
- Alarm Out
1 Channel
- Interface
RJ-45 (10/100Base-T)
- Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP,SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
- User Account
10 users
- IR
IR Range Max upto 20m
- Micro SD
SD, Max 32GB
- Operating Temperature
-10°C~+60°C, 10%~90%
- Power Source
DC12V/AC24V, PoE(802.3af)
- Power Consumption
<10W
- Weatherproof Standard
IK10 & IP66
- Regulatory
CE, FCC and RoHS
- Dimension
Φ160mm×118.5mm
- Weight
1.25kg
-
