Brand: Axis

Axis Q7436

Outstanding Video Processing performance
60/50 fps Support
Coax PTZ Control
Intelligent Video Capabilities
H.264 and Motion JPEG

Qty:

Overview
Specifications
Contact Us

AXIS Q7436

Jual AXIS Q7436 harga distributor di JakartaCCTV, merupakan Video Encoder Blade 6 channel yang berkinerja sangat baik memberikan kualitas video dan audio tinggi namun hemat biaya. AXIS Q7436 mampu menyederhanakan migrasi ke Network Video pada sistem keamanan Anda tanpa perlu meng-upgradenya. Q7436 memungkinkan Anda untuk mengendalikan PTZ Analog Camera melalui kabel coaxial, memberikan penghematan yang signifikan pada saat instalasi. Sebagai tambahan, Video Encoder ini mendukung control standar untuk PTZ Analog Camera dengan serial port. Jadikan Q7436 sebagai salah satu system keamanan pada property Anda dengan mendapatkannya hanya di JakartaCCTV.

Video Encoder Blade 6 channel ini mampu memberikan 2 video streaming secara bersamaan dengan masing-masing format H.264 dan MJPEG, dalam resolusi D1 pada 60 (NTSC)/50 (PAL) fps (720x480 NTSC dan 720x576 PAL). Dengan memiliki frame rate yang cukup tinggi Q7436 mampu memberikan video yang halus pada adegan dengan gerakan cepat. Selain memberikan video yang halus, Q7436 juga bisa mengikuti detail dan perubahan pada daerah yang diawasinya sangat penting dalam pekerjaan forensic. Kompresi format video H.264 berfungsi mengurangi bandwidth secara drastis dan kapasitas penyimpanan data tanpa mengorbankan kualitas gambar. MJPEG yang ada di AXIS Q7436 berguna untuk meningkatkan fleksibilitas. Q7436 menawarkan kemampuan cerdas seperti Motion Detection, Active Tampering Alarm, dan Audio Detection. AXIS Q7436 merupakan cara yang mudah untuk sistem keamanan CCTV yang pintar. Produk dari AXIS terutama AXIS Q7436 hanya bisa Anda dapatkan di JakartaCCTV. JakartaCCTV adalah distributor resmi semua produk AXIS yang memberikan Anda penawaran harga special.

FITUR AXIS Q7436

Video format H.264 dan MJPEG
Resolusi 720x480 NTSC atau 720x576 PAL pada 60 (NTSC)/50 (PAL) fps diresolusi D1
Mendukung PTZ Analog Camera
Bisa menggunakan Power over Ethernet (PoE) sebagai sumber daya

AXIS Q7436 hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga 6 Channel Video Encoder Blade murah. Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Jual 6 Channel Video Encoder Blade murah di Jakartahanya di JakartaCCTV.

Spesifikasi produk

Video Compression	H.264 (MPEG - 4 Part 10/AVC) Baseline, Main and High profile Motion JPEG
Resolution	176x120 to 720x576 NTSC/PAL
Frame Rate	H.264: Up to 60/50 fps (NTSC/PAL) fps in all resolutions Motion JPEG: Up to 60/50 fps (NTSC/PAL) fps in all resolutions
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264
Image settings	Compression, Color, Brightness, Sharpness, Contrast Rotation: 90°, 180°, 270° Aspect ratio correction, Text and image overlay, Privacy mask, Mirroring of images, Enhanced deinterlace filter, Video termination, Anti - aliasing, Noise reduction, Local contrast
Pan/ Tilt/ Zoom	Wide range of analog PTZ cameras supported (drivers available for download at www.axis.com) 100 presets/camera, Guard tour, PTZ control queue Supports Windows compatible joysticks, Compatible with Coaxitron® by Pelco
Security	Password protection, IP address filtering, HTTPS a encryption, IEEE 802.1X a network access control, Digest authentication, User access log
Supported Protocols	IPv4/v6, HTTP, HTTPS a , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP T M , SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One - Click Camera Connection. ONVIF Profile S, specification at www.onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, AXIS Camera Application Platform enabling installation of additional applications
Trigger Events	Intelligent video, Video loss, External inputs
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP External output activation Pre - and post - alarm video buffering PTZ preset, Status LED
Data streaming	Event data
Memory	6x 256 MB RAM, 6x 256 MB Flash
Power	12 V DC, max. 16.3 W
Connectors	6x analog composite video BNC inputs
Operating Conditions	0° C to 45° C ( 32° F to 113° F) Humidity 10–85% RH (non - condensing)
Approvals	EN 55022 Class B, EN 61000 - 3 - 2, EN 61000 - 3 - 3, EN 61000 - 6 - 1, EN 61000 - 6 - 2, EN 55024, FCC Part 15 Subpart B Class B, ICES - 003 Class B, VCCI Class B, C - tick AS/NZS CISPR22, KCC KN22 Class B, IEC/EN/UL 60950 - 1
Weight	303 g ( 0.6 lb)
Included accessories	Installation Guide, Installation and Management Software CD, Windows decoder user license
Video Management Software	AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software
Warranty	Axis 3 - year warranty and AXIS Extended Warranty option, see www.axis.com/warranty
