Brand: Axis

Axis Q7424-R

Rugged design
Extended Temperature Range
SFP Slot for Fiber Connection (now supporting 100 and 1000 Mbps)
Edge storage
AXIS Camera Application Platform
Power over Ethernet
H.264 and Motion JPEG streams

Qty:

Overview
Specifications
Contact Us

AXIS Q7424-R

Jual AXIS Q7424-R harga murah di JakartaCCTV, Video Encoder 1-4 channel mampu bekerja mandiri memungkinkan migrasi dari Analog Camera ke sistem pengawasan berbasis IP secara fleksibel. Q7424-R memiliki desain yang tangguh dan mampu menahan getaran, guncangan, dan suhu ekstrim. Q7424-R mendukung semua jenis Analog Camera termasuk PTZ Camera dan PTZ Dome Camera, menggunakan built-in RS-422 dan RS-485 port. Video Encoder ini juga memiliki slot kartu memori. Jadikan AXIS Q7424-R sebagai salah satu system keamanan pada property Anda dengan mendapatkannya hanya di JakartaCCTV.

AXIS Q7424-R memiliki slot SFP untuk konektivitas melalui kabel optic, yang memberikan fleksibilitas untuk menghubungkan Video Encoder yang hemat biaya untuk jaringan jarak jauh. Q7424-R menawarkan kompresi video H.264 yang efisien, secara drastis mengurangi bandwidth dan kapasitas penyimpanan data tanpa mengorbankan kualitas gambar. MJPEG yang dimiliki Q7424-R untuk menambah fleksibilitasnya. Produk dari AXIS terutama AXIS Q7424-R hanya bisa Anda dapatkan di JakartaCCTV. JakartaCCTV adalah distributor resmi semua produk AXIS yang memberikan Anda penawaran harga special.

FITUR AXIS Q7424-R

Video format H.264 dan MJPEG
Resolusi 720x480 NTSC atau 720x576 PAL pada Full Frame Rate fps diresolusi D1
Mendukung PTZ Analog Camera dan PTZ Dome Camera
Bisa menggunakan Power over Ethernet (PoE) sebagai sumber daya

AXIS Q7424-R hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga 1-4 Channel Video Encoder murah. Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Jual 1-4 Channel Video Encoder murah di Jakartahanya di JakartaCCTV.

Spesifikasi produk

Video Compression	H.264 ( MPEG - 4 P art 1 0/A VC) Baseline and Main Profile Motion JPEG
Resolution	176x120 to 720x576 176x120 to 1536x1 152 for quad view
Frame Rate	H.264: 25/30 (50/60 Hz) fps 15 fps in quad view in full resolution Motion JPEG: 25/30 (50/60 Hz) fps 15 fps in quad view in full resolution
Video Streaming	Multi - stream H.264 and Motion JPEG: One H.264 and one JPEG stream on each channel (8 streams in total) in full frame rate Individually configured streams in max. resolution at 25/30 fps; more streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth; VBR/CBR H.264
Image settings	Compression, Color , Brightness, Contrast, Aspect ratio correction, Mirroring of images, T ext and image overlay , Privacy mask, Enhanced deinterlace filter , Video termination, Anti - aliasing, T emporal noise filtering Rotation: 90°, 180°, 27 0°
Pan/ Tilt/ Zoom	Wide range of analog PTZ cameras supported (drivers available for download at www .axis.com) 1 00 presets/camera, Guard tour , PTZ control queue Supports Windows compatible joysticks
Audio streaming	Two - way
Audio Compression	AAC - LC 8/16 kHz, G.7 1 1 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate
Audio I/O	One external microphone or line input and one line output
IP Address	One IP address for four channels
Security	P assword protection, IP address filtering, HTTPS a encryption, IEEE 80 2.1X a network access control, Digest authentication, User access log
Supported Protocols	IPv4/v6, HTTP , HTTPS a , QoS Layer 3 DiffServ , FTP , CIFS/SMB, SMTP , Bonjour , UPnP™, SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Camera Connection ONVIF Profile S; specification at www .onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, AXIS Camera Application Platform (on one channel)
Trigger Events	Intelligent video, External inputs, Video loss
Event actions	File upload: FTP , HTTP and email Notification: email, HTTP and T CP Video and audio recording to edge storage Pre - and post - alarm video buffering PTZ preset, External output activation
Data streaming	Event data
Casing	Standalone, aluminum casing
Memory	5 12 MB RAM, 128 MB Flash
Power	8–28 V DC, max. 1 0 W, 20–24 V AC, max. 15.6 VA P ower over Ethernet IEEE 80 2.3af/80 2.3at T ype 1 Class 3
Connectors	4 x Analog composite video BNC inputs T erminal block for mono microphone or line input, 6 Vpp max. T erminal block for mono audio output, 2 Vpp max. at 1 kohm 1 0BASE - T/1 00BASE - TX P oE T erminal block for four configurable external inputs/outputs T erminal block for RS485/RS422 (full duplex) AC/DC input terminal block 1 00/1 000 Mbps SFP slot
Edge Storage	SD/SDHC/SDXC slot supporting memory card up to 64 GB (card not included), Support for recording to dedicated network - attached storage (NAS)
Operating Conditions	- 40 °C to 75 °C ( - 40 °F to 167 °F) Humidity 1 0–95% RH (non - condensing)
Approvals	EN 550 22 Class B, EN 50 12 1 - 4, EN 6 1 000 - 3 - 2, EN 6 1 000 - 3 - 3, EN 550 24, EN 6 1 000 - 6 - 1, EN 6 1 000 - 6 - 2, FCC P art 15 Subpart B Class B, ICES - 003 Class B, VCCI Class B, C - tick AS/NZS CISPR 22, KCC KN22 Class B, KN24, IEC/EN/UL 60950 - 1, EN 50 155 (Vibration and Shock Category 1 Class B, T emperature Class TX), NEMA TS 2 (vibration, shock, temperature, humidity), IEC 60068 - 2 - 1, IEC 60068 - 2 - 2, IEC 60068 - 2 - 14, IEC 60068 - 2 - 27, IEC 60068 - 2 - 30, IEC 60068 - 2 - 64, IEC 60068 - 2 - 78, CEN/TS 45545 - 2
Weight	0.8 kg ( 1.7 lb)
Included accessories	Installation Guide, Installation and Management Software CD, Windows decoder user license
Optional accessories	AXIS T83 1 0 Video Surveillance Control Board
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development P artners (not included). For more information, see www .axis.com/products/video/software
Warranty	Axis 3 - year warranty and AXIS Extended W arranty option, see www .axis.com/warranty

Namamu *

Email Anda *

Pertanyaan *

AXIS Q7424-R

FITUR AXIS Q7424-R

Video format H.264 dan MJPEG
Resolusi 720x480 NTSC atau 720x576 PAL pada Full Frame Rate fps diresolusi D1
Mendukung PTZ Analog Camera dan PTZ Dome Camera
Bisa menggunakan Power over Ethernet (PoE) sebagai sumber daya

Spesifikasi produk

Video Compression	H.264 ( MPEG - 4 P art 1 0/A VC) Baseline and Main Profile Motion JPEG
Resolution	176x120 to 720x576 176x120 to 1536x1 152 for quad view
Frame Rate	H.264: 25/30 (50/60 Hz) fps 15 fps in quad view in full resolution Motion JPEG: 25/30 (50/60 Hz) fps 15 fps in quad view in full resolution
Video Streaming	Multi - stream H.264 and Motion JPEG: One H.264 and one JPEG stream on each channel (8 streams in total) in full frame rate Individually configured streams in max. resolution at 25/30 fps; more streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth; VBR/CBR H.264
Image settings	Compression, Color , Brightness, Contrast, Aspect ratio correction, Mirroring of images, T ext and image overlay , Privacy mask, Enhanced deinterlace filter , Video termination, Anti - aliasing, T emporal noise filtering Rotation: 90°, 180°, 27 0°
Pan/ Tilt/ Zoom	Wide range of analog PTZ cameras supported (drivers available for download at www .axis.com) 1 00 presets/camera, Guard tour , PTZ control queue Supports Windows compatible joysticks
Audio streaming	Two - way
Audio Compression	AAC - LC 8/16 kHz, G.7 1 1 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate
Audio I/O	One external microphone or line input and one line output
IP Address	One IP address for four channels
Security	P assword protection, IP address filtering, HTTPS a encryption, IEEE 80 2.1X a network access control, Digest authentication, User access log
Supported Protocols	IPv4/v6, HTTP , HTTPS a , QoS Layer 3 DiffServ , FTP , CIFS/SMB, SMTP , Bonjour , UPnP™, SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www .axis.com AXIS Video Hosting System (A VHS) with One - Click Camera Connection ONVIF Profile S; specification at www .onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, AXIS Camera Application Platform (on one channel)
Trigger Events	Intelligent video, External inputs, Video loss
Event actions	File upload: FTP , HTTP and email Notification: email, HTTP and T CP Video and audio recording to edge storage Pre - and post - alarm video buffering PTZ preset, External output activation
Data streaming	Event data
Casing	Standalone, aluminum casing
Memory	5 12 MB RAM, 128 MB Flash
Power	8–28 V DC, max. 1 0 W, 20–24 V AC, max. 15.6 VA P ower over Ethernet IEEE 80 2.3af/80 2.3at T ype 1 Class 3
Connectors	4 x Analog composite video BNC inputs T erminal block for mono microphone or line input, 6 Vpp max. T erminal block for mono audio output, 2 Vpp max. at 1 kohm 1 0BASE - T/1 00BASE - TX P oE T erminal block for four configurable external inputs/outputs T erminal block for RS485/RS422 (full duplex) AC/DC input terminal block 1 00/1 000 Mbps SFP slot
Edge Storage	SD/SDHC/SDXC slot supporting memory card up to 64 GB (card not included), Support for recording to dedicated network - attached storage (NAS)
Operating Conditions	- 40 °C to 75 °C ( - 40 °F to 167 °F) Humidity 1 0–95% RH (non - condensing)
Approvals	EN 550 22 Class B, EN 50 12 1 - 4, EN 6 1 000 - 3 - 2, EN 6 1 000 - 3 - 3, EN 550 24, EN 6 1 000 - 6 - 1, EN 6 1 000 - 6 - 2, FCC P art 15 Subpart B Class B, ICES - 003 Class B, VCCI Class B, C - tick AS/NZS CISPR 22, KCC KN22 Class B, KN24, IEC/EN/UL 60950 - 1, EN 50 155 (Vibration and Shock Category 1 Class B, T emperature Class TX), NEMA TS 2 (vibration, shock, temperature, humidity), IEC 60068 - 2 - 1, IEC 60068 - 2 - 2, IEC 60068 - 2 - 14, IEC 60068 - 2 - 27, IEC 60068 - 2 - 30, IEC 60068 - 2 - 64, IEC 60068 - 2 - 78, CEN/TS 45545 - 2
Weight	0.8 kg ( 1.7 lb)
Included accessories	Installation Guide, Installation and Management Software CD, Windows decoder user license
Optional accessories	AXIS T83 1 0 Video Surveillance Control Board
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development P artners (not included). For more information, see www .axis.com/products/video/software
Warranty	Axis 3 - year warranty and AXIS Extended W arranty option, see www .axis.com/warranty
