Image Sensor
|
1/4” Progressive scan RGB CMOS 1 megapixel |
Lens
|
2.8 mm, F2.0, fixed iris Horizontal angle of view: 80° |
Light sensitivity
|
1–100000 lux, F2.0 |
Shutter Time
|
1/25000 s to 1/6 s |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC), Motion JPEG |
Video Resolution
|
1280x800 to 160x90 |
Video Framerate
|
25 fps with power line frequency 50 Hz, 30 fps with power line frequency 60 Hz |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264 |
Pan/ Tilt/ Zoom
|
Digital PTZ, Preset positions, Guard tour |
Image settings
|
Mirroring of images |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection. ONVIF; specification at www.onvif.org |
Intelligent Video
|
Support for AXIS Camera Application Platform enabling installation of additional applications |
Trigger Events
|
Intelligent video |
Event actions
|
Video recording to edge storage |
Built-in installation aids
|
Pixel counter |
Casing
|
Metal camera module holder, Plastic camera module casing, Plastic transparent cover and white cover ring |
Memory
|
128 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 1 |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE |
Edge Storage
|
Support for recording to network share (network-attached storage or file server) |
Operating Conditions
|
0 °C to 45 °C (32 °F to 113 °F) Humidity 20–80% RH (non-condensing) |
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, EN/UL 60950-1, MIC Class B |
Weight
|
260 g (0.6 lb) |
Included accessories
|
Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
