Brand: Axis

Axis M3024-LVE

Telp untuk Harga

Compact, vandal-resistant, outdoor-ready design.
1 MP / HDTV 720p.
Day/night functionality and built-in IR illumination.
Input/output ports for external devices.
Power over Ethernet.
Edge storage.

Qty:

Overview
Specifications
Contact Us

AXIS M3024-LVE FIXED DOME NETWORK CAMERA

AXIS M3024-LVE fixed dome camera dirancang untuk pengawasan di dalam ruangan dan dapat juga untuk di gunakan pada luar ruangan, kmaera model ini mampu beroperasi dengan optimal pada suhu -30 °C sampai 50 °C (-22 °F sampai 122 °F).Jual Network Kamera AXIS M3024-LVE harga murah di Jakarta. Kamera yang memiliki resolusi 1 Mega Pixel berkualitas HD 720p dan sensor gambar 1/4” progressive scan RGB CMOS memberikan gambar yang lebih berkualitas, selain itu dengan fitur PoE yang terpasang pada CCTV model ini mampu menyalurkan listrik dengan menggunakan kabel UTP/TSP atau melalui jaringan sehingga dapat menghemat biaya pemasangan.

Network Kamera AXIS M3024-LVE fixed dome. Fixed dome camera AXIS M3024-LVE merupakan CCTV yang dapat terkoneksi dengan jaringan, karena CCTV model ini memiliki konektor yang dapat terhubung dengan RJ45 10BASE-T/100BASE-TX PoE. AXIS M3024-LVE memiliki pilhan bahasa antar muka German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese.

FITUR AXIS M3024-LVE

Resolusi kamera1 Mega Pixel / HDTV 720p.
Sensor gambar 1/4” progressive scan RGB CMOS.
Desain Compact yang kuat terhadap debu.
Memory 256 MB RAM, 128 MB Flash.
Casing aluminum and polycarbonate/ABS.
Power over Ethernet IEEE 802.3af/802.3a Type 1 Class 2 max. 6.3 W.
Instalasi yang fleksibel untuk pemasangan yang mudah.
Media penyimpanan tepi untuk penyimpanan hasil rekaman langsung ke kartu microSDHC.

AXIS M3024-LVE hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah. Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman.

Spesifikasi produk

Image Sensor	1/4” progressive scan RGB CMOS
Lens	M12 mount, Fixed iris, Megapixel resolution, IR corrected 2.8 mm, F2.0 Horizontal angle of view: 77°
Day/Night	Automatically removable infrared-cut filter
Light sensitivity	Color: 0.8-100000 lux, F2.0, B/W: 0.16 lux, F2.0, 0 lux with IR illumination on
Light sensitivity	1/8000 s to 1/6 s
Angle Adjustment	Pan ±175°, Tilt 65°, Rotation ±180°
Video Compression	H.264 Main Profile (MPEG-4 Part 10/AVC), Motion JPEG
Video Resolution	1280x800 (1 MP) to 320x240
Video Framerate	25/30 fps with power line frequency 50/60 Hz
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/CBR H.264
Pan/ Tilt/ Zoom	Digital PTZ
Image settings	Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Backlight compensation, Wide Dynamic Range – dynamic contrast, Text and image overlay, Mirroring of images, Privacy mask Rotation: 0°, 90°, 180°, 270°, including Corridor Format
Security	Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management
Protocol Support	IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org
Analytics	Video motion detection, Active tampering alarm Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap
Trigger Events	Analytics, Edge storage events, External input
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP External output activation Video recording to edge storage Pre- and post-alarm video buffering
Data streaming	Event data
Built-in installation aids	Pixel counter
Casing	IP66- and NEMA 4X-rated, IK10 impact-resistant aluminum casing with transparent, polycarbonate cover and dehumidifying membrane, Encapsulated electronics, Captive screws (resitorx 10) Color: White NCS S 1002-B (for repainting instructions of skin covers, contact your Axis partner)
Memory	256 MB RAM, 128 MB Flash
Power	Power over Ethernet IEEE 802.3af/802.3a Type 1 Class 2 max. 6.3 W
Illumination LED	High-efficiency, long-life 850 nm IR LEDs. Range of reach up to 10 m (33 ft) depending on scene
Connectors	Male RJ45 10BASE-T/100BASE-TX PoE on a 2 m (6.6 ft) network cable, warranty can be maintained even when cable is cut-for more information, contact your Axis partner Terminal block for 1 alarm input and 1 output
Edge Storage	Support for microSD/microSDHC/microSDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com
Operating Conditions	-30 °C to 50 °C (-22 °F to 122 °F) Humidity 10–100% RH (condensing)
Approvals	EN 55022 Class B, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC/EN/UL 60950-22, EN 50581, IEC 60529 IP66, NEMA 250 Type 4X, IEC 62262 IK10
Weight	770 g (1.7 lb)
Included accessories	Installation Guide, Windows decoder 1-user license, Drill hole template, Resitorx L-key, Terminal block connector
Optional accessories	AXIS T91 Mount Accessories, AXIS T94F01D Pendant Kit, AXIS T94F01L Recessed Mount Kit, AXIS T94F01M J-Box/Gang Box Plate, AXIS T94F01P Conduit Back Box, AXIS T94F01S Mount Bracket, AXIS T94F02D Pendant Kit with sunshield, Network Cable Coupler IP66, Network Cable Coupler Indoor, Network Cable Coupler Indoor Slim, Skin covers (White/Black)
Video Management Software	AXIS Camera Companion, AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software
Language	German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese
