Sony SSC-G103

Image Sensor

1/3-type 760H Super HAD CCD II

Image Sensor (Number of Effective Pixels)

Approx. 0.44 Megapixels

Signal System

PAL

Minimum Illumination (50 IRE)

Color: 0.15 lx (F1.2 AGC ON)
B/W: 0.10 lx (F1.2 AGC ON)

Minimum Illumination (30 IRE)

Color: 0.08 lx (F1.2 AGC ON)
B/W: 0.03 lx (F1.2 AGC ON)

S/N Ratio

More than 55 dB (AGC OFF)

Gain

Auto (ON/OFF)

Shutter Speed

Fixed (1/50s, Default), Auto or 8 Fixed steps selectable

Sync System

Internal/AC line lock selectable

White Balance

ATW (2000K to 10000K)
ATW-pro (2500K to 6000K)

Powered Zoom

No

Powered Focus

No

Horizontal Resolution

540 TVL

Infrafed Illuminators

No

Day/Night

Yes (Electrical D/N)

Image Enhancement

Yes (ATR-Lite, on/off), Yes (iBLC, on/off)

Noise Reduction

Yes (2DNR, on/off)

Analog Monitor Output

VBS: 1.0 Vp-p

Power Requirements

AC24V ±10%, DC12V ±10%

Lens Mount

CS Mount

Power Consumption

1.4 W max.

Operating Temperature

-10°C to +50°C
14°F to 122°F

Storage Temperature

-40 °C to +60 °C
-40°F to +140°F

Operating Humidity

20% to 80%

Storage Humidity

20% to 95%

Vandal Resistant

No

Dimensions *1

63.2 x 57.2 x 117.6 mm
2 1/2 x 2 3/8 x 4 3/4 inches

Mass

250 g
9 oz

Safety Regulations

EN55022(Class A)+EN50130-4
EN55022(Class A)+EN55024
AS/NZS CISPR22 (EN55022) Class A
IEC60065
GOST-R IEC60065 compliance

Ingress Protection

No

Supplied Accessories

Operating Instructions (1)
Lens Mount Cap (1)
