| VIDEO |
|
| Imaging Device |
1/2.8" 2.38M CMOS |
| Total / Effective Pixels |
1,952(H) x 1,116(V), 2.18M / 1,944(H) x 1,104(V) , 2.14M |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.3Lux (1/30sec, F1.6, 50IRE), B/W : 0.03Lux (1/30sec, F1.6, 50IRE) |
| S / N Ratio |
50dB |
| Video output |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 576, for installation
DIP connector type |
| LENS |
|
| Focal Length (Zoom Ratio) |
4.44 ~ 142.6mm (Optical 32x) |
| Max. Aperture Ratio |
F1.6(Wide) / F4.4(Tele) |
| Angular Field of View |
H : 62.8°(Wide) ~ 2.23°(Tele) / V : 36.80°(Wide) ~ 1.26°(Tele) |
| Min. Object Distance |
1.5m (4.92ft) |
| Focus Control |
Auto / Manual / One push |
| Lens / Mount Type |
DC auto iris / Board-in type |
| OPERATIONAL |
|
| Camera Title |
Off / On (Displayed up to 45 characters) |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC |
| Wide Dynamic Range |
120dB |
| Contrast Enhancement |
SSDR (Samsung Super Dynamic Range) (Off / On) |
| Digital Noise Reduction |
SSNRIII (2D+3D noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (4ea 4 points polygonal zones) |
| Privacy Masking |
Off / On (32 zones with 2 points of rectangle) |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor / Mercury |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital Zoom |
16x |
| Flip / Mirror |
Off / On |
| Intelligent Video Analytics |
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection |
| Alarm I/O |
Input 1ea / Output 1ea (Relay) |
| Remote Control Interface |
RS-485 |
| RS-485 Protocol |
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE |
| Alarm Triggers |
Motion detection, Tampering, Audio detection, Face detection, Video analytics, Alarm input, Network disconnection |
| Alarm Events |
File upload via FTP and E-mail, Notification via E-mail, Local storage(SD/SDHC/SDXC) or
NAS recording at Network disconnected & Event (Alarm Triggers), External output |
| NETWORK |
|
| Ethernet |
RJ-45 (10/100BASE-T ) |
| Video Compression Format |
H.264 (MPEG-4 part 10/AVC), MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| Max. Framerate |
H.264 : Max. 60fps at all resolutions
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps |
| Smart Codec |
Manual mode (Area-based : 5ea), Face detection mode |
| Video Quality Adjustment |
H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method |
H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 profiles) |
| Audio In |
Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio out |
Line out (3.5mm stereo mini jack), Max output level : 1 Vrms |
| Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,
G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| Audio Communication |
Bi-directional audio |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
10 users at unicast mode |
| Edge Storage |
SD/SDHC/SDXC - motion Images recorded in the SD/SDHC/SDXC memory card can be
downloaded. NAS (Network Attached Storage) |
| Application Programming Interface |
ONVIF profile S, SUNAPI 2.0, SVNP 1.2 |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese,
Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian |
| Web Viewer |
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 / 10.8
Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11),
Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 32)
Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
* Mac OS X only |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
|
| operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| ELECTRICAL |
|
| Input Voltage / Current |
12V DC, PoE (IEEE802.3af class 3) |
| Power Consumption |
Max. 9.0W (12V DC) / Max. 10.0W (PoE) |
| MECHANICAL |
|
| Color / Material |
Dark gray / Metal |
| Dimensions (WxHxD) |
72.0 x 59.9 x 135.4mm (2.83" x 2.36" x 5.33") |
| Weight |
540g (1.19 lb) |
