Produk sebelumnyaMicrolexus MNR-7604NI-SE/P

Brand: Microlexus

Microlexus MNR-7616NI

Rp 2.200.000

Harga Lama: Rp 9.000.000

tidak termasuk pengiriman

• Third-party network cameras supported
• Up to 5 Megapixels resolution recording
• HDMI and VGA output at up to 1920×1080P resolution
• 16-ch synchronous playback
• HDD quota and group management

Qty:

Overview
Contact Us

Video/Audio Input

IP Video Input:	16-ch
Two-way Audio:	1-ch RCA(2.0Vp-p, 1kΩ)

Video/Audio Output

VGA Output:	1-ch, resolution: 1920×1080P/60Hz,1600×1200/60Hz,1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
CVBS Output:	1-ch, BNC (1.0 Vp-p, 75 Ω) Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
HDMI Output:	1-ch, resolution: 1920 × 1080P /60Hz, 1920 × 1080P /50Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Recording resolution:	5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Audio Output:	1-ch BNC(Linear electrical level, 600Ω)
Playback Resolution:	5MP /3MP / 1080P / UXGA / 720P / 4CIF / VGA / DCIF / 2CIF / CIF / QCIF
Synchronous Playback:	16-ch

Hard Disk Driver

Interface Type:	2 SATA Interfaces
Capacity:	Up to 4TB capacity for each disk

External Interface

Network Interface:	1 RJ45 10M/100M/1000M adaptive Ethernet Interface
USB Interface:	2 USB 2.0 Interfaces
Serial Interface:	1 RS-232 interface;1 RS-485 interface (reserved);
Alarm Input:	4-ch
Alarm Output:	2-ch

General

Power Supply:	12 VDC
Consumption:	≤ 13 W (without hard disk or DVD-R/W)
Working Temperature:	-10 °C ~ +55 °C
Working Humidity:	10%~90%
Chassis:	19-ich rack-mounted 1U chassis
Dimensions:	445 × 261 ×44.5 mm (W x D x H)
Weight:	≤ 4 Kg ( without hard disk or DVD-R/W )
