Image Sensor
|
1/3" Progressive Scan CMOS |
Min.Illumination
|
0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR |
Shutter speed
|
1/25 s to 1/100,000 s |
Lens
|
4mm@ F2.0, Angle of view: 79° (6mm, 12mm optional) |
Lens Mount
|
M12 |
Day/Night
|
IR cut filter with auto switch |
Digital Noise Reduction
|
3D DNR |
Wide Dynamic Range
|
Digital WDR |
Video Compression
|
H.264/ MJPEG |
Video Bit Rate
|
32 Kbps – 16 Mbps |
Dual Stream
|
Yes |
Max. Resolution
|
1920 × 1080 |
Frame Rate
|
50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) |
Image settings
|
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
Backlight Compensation
|
Yes, zone optional |
ROI
|
Yes, up to 4 configurable areas |
Network storage
|
NAS |
Alarm Triggers
|
Motion detection, Dynamic analysis, Tampering alarm |
Protocol
|
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Security
|
User Authentication, Watermark |
Standard
|
ONVIF, PSIA, CGI, ISAPI |
Communication interface
|
1 RJ45 10M/100M Ethernet interface |
Reset Button
|
Yes |
Operating Conditions
|
-30 °C – 60 °C (-22 °F – 140 °F) Humidity 95% or less (non-condensing) |
Power Supply
|
12 V DC ± 10% , PoE (802.3af) |
Power Consumption (±10%)
|
Max. 7 W |
Ingress Protection
|
IP66 |
IR Range
|
30 meters |
Dimension
|
60.4×76.9×139.28 mm (2.4” × 3.0” × 5.5”) |
Weight
|
500g (1.1 lbs) |
