Two-way audio input
|
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
|
IP video input
|
32-ch |
|
Incoming bandwidth
|
256Mbps |
|
Outgoing bandwidth
|
256Mbps |
|
Remote connection
|
128 |
|
Recording Resolution
|
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
HDMI Output
|
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 x 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60H |
|
VGA Output
|
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
|
Live view / Playback resolution
|
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Synchronous playback
|
32-ch |
|
Network Protocol
|
IPV4 and IPV6, TCP/IP, DHCP, HIK Cloud P2P (DDNS of the Network Hikvision), DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, DYNDNS, NO - IP, FTP, IP filter, HTTP, RTSP, search management IP, alarm server, UDP, PPPoE. Send email for 3 differents addres with alerts and photos. Alarm of the disconnect networking |
|
SATA
|
4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
|
Capacity
|
Up to 6TB capacity for each HDD |
|
Network interface
|
2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
|
Serial Interface
|
RS-232; RS-485 |
|
USB interface
|
Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
|
Alarm Inputs / Output
|
16-ch - 4-ch |
|
Power Supply
|
100~240VAC |
|
Consumption
|
≤ 20W |
|
Working Temperature/Humidity
|
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
|
Chassis
|
19-inch rack-mounted 1.5U chassis |
|
Dimension
|
445 × 390 × 70mm (17.5 ×15.3 × 2.8 inch) |
|
Weight
|
≤ 5 Kg (11 lb) |
