Two-way audio input
|
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
|
IP video input
|
32-ch |
|
Remote connection
|
128 |
|
Incoming bandwidth
|
160Mbps |
|
Outgoing bandwidth
|
80Mbps |
|
HDMI / VGA output
|
1-ch, resolution: 1080P: 1920×1080/60Hz; SXGA: 1280×1024/60Hz; 720P: 1280×720/60Hz; XGA: 1024×768/60Hz |
|
Recording Resolution
|
6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Frame Rate
|
Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
|
Audio Output
|
1-ch, RCA (Linear, 1kΩ) |
|
Synchronous playback
|
16-ch |
|
Capability
|
16-ch@4CIF, 12-ch@720P, 6-ch@1080P |
|
Live view / Playback resolution
|
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
SATA
|
4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
|
Capacity
|
Up to 6TB capacity for each HDD |
|
Network interface
|
1, RJ45 10M / 100M Ethernet interface |
|
USB interface
|
Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
|
Consumption
|
≤ 20W |
|
Alarm Inputs / Output
|
16-ch - 4-ch |
|
Supported standard
|
AF and AT |
|
Interface
|
16 independent 100 Mbps PoE network interfaces |
|
Max. Power
|
200W |
|
Power Supply
|
100~240VAC |
|
Working Temperature/Humidity
|
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
|
Chassis
|
19-inch rack-mounted 1.5U chassis |
|
Dimension
|
445 × 390 × 70mm (17.5 ×15.3 × 2.8 inch) |
|
Weight
|
≤ 4 Kg (8.82 lb) |
