Brand: CP Plus

CP Plus CP-UNC-TP13FL2CD

Rp 10.000.000

tidak termasuk pengiriman

1/3” 1.3MP Progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1.3M(1280×960)&25/30fps@720P(1280×720)
WDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
2.8~12mm varifocal lens
Built-in 2/1 alarm in/out
Max. IR LEDs length 20m
Micro SD memory, IP66, PoE
Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 1.3Megapixel CMOS
Minimum Illumination	0. 1Lux/F1.2 (Color), 0.005Lux/F1.2(B/W);0Lux/F1.2(IR on)
Shutter Speed	Auto/Manual 1/3~1/10000
White Balance	Auto
AGC control	Auto/Manual
Back Light Comp.	BLC / HLC / WDR (128dB)
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
Video Output	1 channel BNC(1.0Vp-p, 75Ω)
IR	20m
ICR	Auto(ICR) / Color / B/W
Lens	2.8~12mm
Privacy Masking	Up to 4 areas
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V(AC24 optional), PoE(802.3af)
Power Consumption	<10W
Weatherproof Standard	IP66
Dimension	ф104mm × 306.7mm
Weight	1.25Kg
Micro SD	Max 32GB
User Account	10 users
Alarm IN	2 Ch.
Alarm Out	1 Ch.
Audio Input	1 channel
Audio Output	1 channel
Audio Compression	G.711a / G.711u(64kbps)/PCM(128kbps)

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 1.3Megapixel CMOS
Minimum Illumination	0. 1Lux/F1.2 (Color), 0.005Lux/F1.2(B/W);0Lux/F1.2(IR on)
Shutter Speed	Auto/Manual 1/3~1/10000
White Balance	Auto
AGC control	Auto/Manual
Back Light Comp.	BLC / HLC / WDR (128dB)
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
Video Output	1 channel BNC(1.0Vp-p, 75Ω)
IR	20m
ICR	Auto(ICR) / Color / B/W
Lens	2.8~12mm
Privacy Masking	Up to 4 areas
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V(AC24 optional), PoE(802.3af)
Power Consumption	<10W
Weatherproof Standard	IP66
Dimension	ф104mm × 306.7mm
Weight	1.25Kg
Micro SD	Max 32GB
User Account	10 users
Alarm IN	2 Ch.
Alarm Out	1 Ch.
Audio Input	1 channel
Audio Output	1 channel
Audio Compression	G.711a / G.711u(64kbps)/PCM(128kbps)
