Action on event
|
Mail / FTP / Recording / Alarm / PTZ Activation / Message / Buzzer
|
|
Alarm Input
|
16 channels
|
|
Audio
|
Two-way
|
|
Certification
|
CE / FCC
|
|
CMS Software
|
PSS
|
|
Data Flow Record
|
Up to 32 Mbps
|
|
Detection of events
|
A systemic events / Camera events
|
|
Digital Zoom
|
Yes
|
|
E-Map
|
Supported
|
|
Ethernet
|
RJ-45 Port (10/100/1000)
|
|
|
Photo in JPEG
|
|
Functions when playing
|
Play, Pause, Stop, Rewind, Slow Play, Next File, Previous File, Next Camera, Previous camera, Full Screen, Repeat, Shuffle the shuffle, Backup selection Digital Zoom
|
|
HDD
|
2 x SATA HDD, maximum capacity 6TB (3TB per HDD)
|
|
Weight
|
2.3 Kg without HDD
|
|
Interval recording
|
1-120 min. (default 60 min.)
|
|
Video Compression
|
H.264 / MPEG-4
|
|
Maximum speed record
|
400 fps. / Sec @ D1, 200 fps. / Sec @720P, 100 sn. / S @ 1080P
|
|
Mobile devices
|
Live with control Pan / Tilt through iPhone, BlackBerry, WinMobile, Symbian and Android with the built-in browser
|
|
Search Options
|
Time / Date / Event (motion alarm)
|
|
Event recording
|
Recording motion / alarm recording
|
|
Power
|
DC 12 V / 3.3 A
|
|
OSD Menu
|
Camera title, time, video loss, camera lock, motion detection, recording
|
|
Memory
|
128 megabytes RAM DDR 1
|
|
Full Monitor
|
1 / 4 / 8 / 9 / 16
|
|
Number of managed cameras
|
16 channels
|
|
Support PTZ
|
Yes
|
|
Processor
|
ST7108
|
|
Operating Temperature
|
-10°C to +50°C
|
|
Operating Humidity
|
10% - 90%
|
|
Add a camera
|
Manual / Intelligent search
|
|
Relay Output
|
3 Channels
|
|
Recording Mode
|
Manual, Scheduler / Schedule, Motion Detection (Video detection : motion detection, camera blind), Alarm, Stop
|
|
Display Mode
|
Live / Playback / Full view / ratio of the original appearance
|
|
Split Screen
|
1 / 4 / 8 / 9 / 16
|
|
Distribution playback display
|
1 / 2 / 4 / 8 / 16
|
|
Distinction
|
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
|
|
Dimensions
|
1 U, 375 x 285 x 45 mm
|
|
Schedule recording
|
Manual selection / Profile / Weekly Mode
|
|
Network Protocol
|
HTTP, TCP / IP, UPNP, RTSP, UDP, SMTP, NTP, DNS, IP Filter, PPPOE, DDNS, FTP, ONVIF
|
|
Management
|
User / Group
|
|
Type of user groups
|
Administrator / User / Up to 20 User simultaneously
|
|
USB Port
|
2 x USB 2.0
|
|
User Permissions
|
Live monitoring / playback / System Configuration / Camera / Configuration / Event Service
|
|
Video Output
|
1 x HDMI (Video + Audio), 1 x VGA
|
|
Search Events
|
All / Time / Channel / Event Type / Event Identification
|
