Produk sebelumnyaCP Plus CP-UAP-SY37C-EH

Brand: CP Plus

CP Plus CP-UAP-SY37CL10-EH

Rp 22.400.000

tidak termasuk pengiriman

1/4" Super HAD CCD II
High Resolution of 600TVL
Min. Illumination of 0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
Powerful 37x Optical Zoom
Day/Night (ICR), DNR (2D and 3D), Auto iris, Auto focus, AWB, AGC, BLC
Max 240 °/s pan speed, 360° continuous pan rotation & auto flips with no blind spot monitor
Up to 255 preset, 5 auto scan, 8 tour, 5 patternAuto recognition of general protocols Pelco-P/D
The longest distance of the build-in IR lamp is over 100m
Build-in 7/2 channel alarm input/output
OSD and operation prompts of various languages
IP66 all-environments protection, 4000V thunder-proof

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4" Super HAD CCD II
Pixels	PAL: 752(H) x 582(V), NTSC: 768(H) x x494(V)
Resolution	600 TVL
Min. Illumination	0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
S/N Ratio	more than 50 dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	37x
Iris Control	Auto Iris
Focus Mode	Auto
White Balance (AWB)	AWB (3000 to 7500K), ATW(2000 to 1000K), Indoor(3200K), Outdoor(5800K), Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
Special Functions	Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360° endless, Vertical: -2°~90° auto flip 180° to continue monitor
Surge Protection	yes
Tilt Range	Horizontal: 0°~360° endless, Vertical: -2°~90° auto flip 180° to continue monitor
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Alarm	7/2 alarm input/output, Triggering Preset/Tour/Pattern/Scan/On-off Output
Number of Presets	255
Operating Temp	-20ºC ~ 60ºC
IP Rating	66
Communication	RS485
Lens	3.4mm ~ 122.4mm
Video Output	CVBS: 1.0Vp-p / 75Ω
Power Supply	AC 24V/3A (±10%)
Power Consumption	12W/30W(IR lamp on)
Zoom Digital	16x
Certifications	CE, FCC and RoHS
Weight	7.0kg
Gamma	0.45
IR LED	Auto / Near light / Far light / OFF, 6 Near light + 8 Far light, up to 100m
Dimensions	Φ230(mm) x 352(mm)

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/4" Super HAD CCD II
Pixels	PAL: 752(H) x 582(V), NTSC: 768(H) x x494(V)
Resolution	600 TVL
Min. Illumination	0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
S/N Ratio	more than 50 dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	37x
Iris Control	Auto Iris
Focus Mode	Auto
White Balance (AWB)	AWB (3000 to 7500K), ATW(2000 to 1000K), Indoor(3200K), Outdoor(5800K), Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
Special Functions	Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360° endless, Vertical: -2°~90° auto flip 180° to continue monitor
Surge Protection	yes
Tilt Range	Horizontal: 0°~360° endless, Vertical: -2°~90° auto flip 180° to continue monitor
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Alarm	7/2 alarm input/output, Triggering Preset/Tour/Pattern/Scan/On-off Output
Number of Presets	255
Operating Temp	-20ºC ~ 60ºC
IP Rating	66
Communication	RS485
Lens	3.4mm ~ 122.4mm
Video Output	CVBS: 1.0Vp-p / 75Ω
Power Supply	AC 24V/3A (±10%)
Power Consumption	12W/30W(IR lamp on)
Zoom Digital	16x
Certifications	CE, FCC and RoHS
Weight	7.0kg
Gamma	0.45
IR LED	Auto / Near light / Far light / OFF, 6 Near light + 8 Far light, up to 100m
Dimensions	Φ230(mm) x 352(mm)
