Brand: CP Plus

CP Plus CP-UAP-SC23CL6

Rp 11.400.000

tidak termasuk pengiriman

1/4" CMOS
High Resolution of 600TVL
Min. Illumination of 0.5Lux@F1.6
Powerful 23x Optical Zoom
Day/Night (ICR), 2D-DNR, , Auto iris, Auto focus, AWB, AGC, BLC
Max 240 °/s Pan Speed, 360° Continuous Pan Rotation and Auto Flips with no Blind Spot Monitor
Up to 255 Preset, 5 Auto Scan, 8 Tour, 5 PatternAuto Recognition of General Protocols Pelco-P/D
The max. IR Distance is over 60m
OSD and Operation Prompts of Various Languages
Auto Restore to Previous PTZ and Lens Status after Power Failure
IP66 All-Environments Protection, 4000V Thunder-Proof

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4” CMOS
Pixels	640H) × 480(V)
Resolution	600 TVL
Min. Illumination	0.5 Lux@F1.6
S/N Ratio	more than 50dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	23x
Lens	3.9 mm~89.7mm
Focus Mode	Auto
Iris Control	Auto Iris
Gamma	0.45
White Balance (AWB)	Auto/Manual
Gain Control (AGC)	Auto/Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
IR LED	The max. IR distance is over 60m
Special Functions	Day/Night (ICR), 2D-DNR, Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360°endless, Vertical: -15°~90° auto flip 180° to continue monitor
Tilt Range	Horizontal: 0°~360°endless, Vertical: -15°~90° auto flip 180° to continue monitor
Number of Presets	255
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Surge Protection	Yes
Communication	RS485
Video Output	CVBS: 1.0Vp-p / 75Ω
Power Supply	AC 24V/2.2A (±10%)
Power Consumption	13W(Indoor), 31W(Outdoor, heater on)
IP Rating	IP66
Dimensions	Φ185(mm) x 299(mm)
Weight	5.0kg
Operating Temp	-40ºC ~ 60ºC
Certifications	CE, FCC and RoHS
