Image Sensor
|
Progressive scan RGB CMOS 1/2.8" |
Lens
|
2.8–8 mm: 120°–40° viewa , F1.3 |
Day/Night
|
Automatically removable infrared-cut filter |
Min.Illumination
|
Color: 0.18 lux, B/W: 0.04 lux, F1.3; |
Shutter Time
|
1/143000 to 2 s |
Pan/ Tilt/ Zoom
|
Digital PTZ, Uploadable PTZ driver (Pelco D pre-installed) |
Video Compression
|
High Profile |
Video Resolution
|
WUXGA 25/30 fps (no WDR): 1920x1200 to 160x90 HDTV 1080p 25/30 fps (WDR): 1920x1080 to 160x90 HDTV 1080p 50/60 fps (no WDR): 1920x1080 to 160x90 |
Video Frame Rate
|
50/60 fps (no WDR) |
Video Streaming
|
MBR H.264 |
Image settings
|
WDR-Forensic Capture: Up to 120 dB depending on scene, Auto-rotation, Barrel distortion correction, Day/Night shift level, Electronic Image Stabilization, Local contrast, Defogging |
Audio streaming
|
Two-way |
Audio Compression
|
AAC-LC 8/16/32 kHz |
Audio Input / Output
|
External balanced/unbalanced microphone or line input, line output |
Security
|
Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com. AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification available at www.onvif.org |
Trigger Events
|
Shock detection |
Event actions
|
File upload: FTP, HTTP, HTTPS, network share and email Send video clip Notification: email, HTTP, HTTPS and TCP Overlay text, Send SNMP Trap Video and audio recording to edge storage Pre- and post-alarm video buffering External output activation, Day/night vision mode, Play audio clip, Status LED, WDR mode |
Data streaming
|
Event data |
Built-in installation aids
|
Leveling assistant, Auto rotation, Camera orientation aid |
Casing
|
Camera: Metal (zinc) |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
8–28 V DC or Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3 max. 7.3 W |
Connectors
|
DC input, Terminal block for two configurable inputs/outputs (12 V DC output, max. load 50 mA) |
Edge Storage
|
microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) |
Operating Conditions
|
0 °C to 55 °C (32 °F to 131 °F) Up to 60 °C (140 °F) when mounted inside AXIS T92E20 Housing |
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, IEC/EN/UL 60950-1 |
Weight
|
914 g (2 lb) |
Included accessories
|
Stand, Connector kit, Resistorx T20 tool, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see: www.axis.com/products/video/software |
