Image Sensor
|
1/2.5” progressive scan CMOS |
Min.Illumination
|
Color: 1.4 lux at F1.6, B/W: 0.3 lux at F1.6 For -LE models 0 lux with IR illumination on |
Shutter Time
|
1/32500 s to 1/2 s (50/60 Hz) |
Video Compression
|
H.264 High, Main and Baseline profiles (MPEG-4 Part 10/AVC), Motion JPEG |
Video Resolution
|
3840x2160 4K Ultra HD to 320x240 Meets relevant parts of SMPTE ST 2036-1 (UHDTV) |
Video Frame Rate
|
Up to 25/30 fps (50/60 Hz) in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/CBR H.264 |
Image settings
|
Rotation: 0°, 180° |
Pan/ Tilt/ Zoom
|
Digital PTZ |
Security
|
Password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSb , SSL/TLSb , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform, specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection. ONVIF Profile S, specification available at www.onvif.org |
Intelligent Video
|
Video motion detection, Support for AXIS Camera Application Platform enabling installation of additional applications |
Trigger Events
|
Detectors: Day/Night Mode, Live Stream Accessed Tampering Hardware: Network, Temperature Input Signal: Manual Trigger, Virtual Inputs Storage: Disruption, Recording System: System Ready Time: Use Schedule, Recurrences |
Event actions
|
File upload via FTP, HTTP and email Notification via email, HTTP and TCP Video recording to edge storage, day/night mode 40 MB Pre- and post-alarm video buffering |
Built-in installation aids
|
Pixel counter, Remote zoom (3-3.5x optical), Remote focus |
Data streaming
|
Event data |
Casing
|
IP66-and NEMA 4X-rated casing (polyester polycarbonate blend) |
Memory
|
1024 MB RAM, 256 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3 max 12.9 W |
Connectors
|
RJ-45 10BASE-T/100BASE-TX/1000BASE-T PoE |
Edge Storage
|
Supports microSD cards with up to 64 GB of storage. For best recording performance, use a microSDHC or microSDXC card with speed class 10 (card not included) Support for recording to dedicated network-attached storage (NAS) |
Operating Conditions
|
-30 °C to 50 °C (-22 °F to 122 °F) Humidity 10–100% RH (condensing) |
Approvals
|
EN 55022 Class B |
Weight
|
With weather shield: 854 g (1.88 lb) |
Included accessories
|
Mounting bracket, Weather shield, Drill template, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Companion (software included on CD) – Basic surveillance for small businesses, where video is recorded to edge storage AXIS Camera Station (sold separately) — Fully featured surveillance for medium-sized installations, where video is recorded on a system server. For more information and software applications from partners, see www.axis.com/products/video/software/ |
