Video Compression
|
H.264 Baseline and Main Profiles ( MPEG - 4 Part 10/AVC) Motion JPEG |
|
Resolution
|
720x576 to 176x120, 1536x1152 to 176x120 for quad view |
|
Frame Rate
|
H.264: 25/30 fps (50/60 Hz) 15 fps in quad view in full resolution Motion JPEG: 25/30 fps (50/60 Hz) 15 fps in quad view in full resolution |
|
Video Streaming
|
One individually configured H.264 and one Motion JPEG stream per channel at full frame rate More streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth VBR/CBR H.264 |
|
Image settings
|
Compression, Color, Brightness, Contrast, Text and image overlay, Mirroring of images, Privacy mask, Aspect ratio correction, Enhanced deinterlace filter, Video termination, Antialiasing, Temporal noise filtering Rotation: 90°, 180°, 270° |
|
Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported a Support for one PTZ driver Multiple camera presets supported, Guard tour, PTZ control queue Supports Windows compatible joysticks |
|
Audio streaming
|
Two - way, full duplex and half duplex (2 mic/line inputs, 1 line output) |
|
Audio Compression
|
n: AAC - LC 8 or 16 kHz 8–64 kbit/s G.711 μ - law PCM 8 kHz 64 kbit/s G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s Out: G.711 μ - law PCM 8 kHz 64 kbit/s, μ - law PCM 16 kHz 128 kbit/s G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s |
|
Audio I/O
|
External microphone input or line input Line level output Audio streaming, record (AU) and play uploaded (WAV, AU) clips AU (G.711 μ - law 8 - bit 8/16 kHz mono), WAV (PCM 16 - bit 8/16 kHz mono) |
|
IP Address
|
One IP address for four channels |
|
Security
|
Password protection, IP address filtering, HTTPS b encryption, IEEE 802.1X b network access control, Digest authentication, User access log |
|
Supported Protocols
|
IPv4/v6, HTTP, HTTPS b , SSL/TLS b , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
|
Application Programming Interface
|
Open API for software integration, including VAPIX®, specifications at www.axis.com ONVIF Profile S, specifications at www.onvif.org |
|
Intelligent Video
|
Video motion detection, Active tampering alarm, Audio detection |
|
Trigger Events
|
Intelligent video, External inputs, Video loss, Edge storage events |
|
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video and audio recording to edge storage Pre - and post - alarm video buffering PTZ preset, Play audio clip, External output activation |
|
Data streaming
|
Event data |
|
Built-in installation aids
|
Pixel counter |
|
Casing
|
Compatible with AXIS 291 1U Video Server Rack and AXIS Q7920 Video Encoder Chassis |
|
Memory
|
512 MB RAM, 128 MB Flash |
|
Power
|
12 V DC, max. 6 W |
|
Connectors
|
4x analog composite video BNC inputs 1x Terminal block for four configurable external inputs/outputs (on back of rack) 1x Terminal block for RS - 485/RS - 422 (2–wire) 2x 3.5 mm jacks for microphone or line input (mono) 1x 3.5 mm jack for audio output (mono) |
|
Edge Storage
|
Support for recording to dedicated network - attached storage (NAS) |
|
Operating Conditions
|
0 °C to 45 °C ( 32 °F to 113 °F) Humidity 20–80% RH (non - condensing) |
|
Approvals
|
EN 55022 Class B, EN 55024, EN 61000 - 3 - 2, IEC/EN/UL 60950 - 1, EN 61000 - 3 - 3, EN 61000 - 6 - 1, EN 61000 - 6 - 2, FCC Part 15 Subpart B Class B, ICES - 003 Class B, VCCI Class B, C - tick AS/NZS CISPR 22 Class B, KCC KN22 Class A, KN24 EN 55022 Class B for AXIS 291 1U Video Server Rack and AXIS Q7920 Video Encoder Chassis |
|
Weight
|
210 g ( 0.46 lb) |
|
Included accessories
|
Installation Guide, Installation and Management Software CD, Windows decoder licenses |
|
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
|
Required Hardware
|
AXIS 291 1U Video Server Rack or AXIS Q7920 Video Encoder Chassis |
|
Warranty
|
Axis 3 - year warranty, see www.axis.com/warranty |
