| Image Sensor |
1/3 EFFIO-E CCD |
| Effective Pixels |
1020(H)×508(V) |
| Resolution |
700TVL |
| Video System |
PAL/NSTC |
| Focal length |
f=3.0 ~ 90.0mm(30X) |
| Zoom |
30X |
| Minimum Illumination |
color:0.01Lux B & W :0.001Lux |
| Focus |
Automatic / manual / automatic, full digital high speed continuous focusing |
| Iris |
Automatic |
| Menu |
Full screen menu |
| HLC |
ON / OFF |
| Privacy masking |
4 privacy masking regions |
| Mirror Image |
ON / OFF |
| White Balance |
Auto |
| IR-CUT |
No |
| Sensing IR |
YES |
| Preset position |
256 |
| Scan pattern |
4 |
| Cruise trajectory |
8 |
| Other scanning |
Level of support scanning, two regional scan, random scan |
| Rotation range |
Level 360°infinite, vertical 180 °, automatic turnover |
| Speed of rotation |
Horizontal and vertical: a minimum of 0.01, maximum 300 degrees / sec |
| Means of communication |
RS-485,PELCO D and PELCO P |
| Temperature control system |
Built-in temperature control system |
| The ball machine material |
Metal cast aluminum enclosure |
| Color /B & W |
Color / black and white / automatic |
| Synchronization mode |
Internal synchronization |
| Power |
DC12V 3A |
| Memory power |
YSE |
| Ambient temperature |
Minus 20 °C ~ 50 °C (Optional temperature control components), <95% RH |
| Power consumption |
≤20W |
| Size / Weight |
about 3.5KG(net weight) |
