Main Processor
|
HI3521 |
Operating System
|
Embedded LINUX |
Video Inputs
|
8 Channel, AHD |
Video Output
|
1 VGA, 1 TV,1 HDMI |
Audio Input
|
4Channel, RCA |
Audio Output
|
1 Channel, RCA |
Interface
|
RS485 |
Protocol PTZ
|
Pelco-D, Pelco-P, Sony, Sharp, Panasonic, Samsung and Other Protocols |
Baud Rate
|
1200~115200 |
PTZ Address
|
0~255 |
VGA
|
Resolution: 1024×768, 1280×720, 1280×1024, 1920×1080 |
Display Split
|
16 Channel/8 Channel/4 Channel / 1Channel |
Privasi masking
|
4 Rectangular Zones (Each camera) |
OSD Menu
|
Camera title, Time, Video loss, Alarm, Motion detection, Recording |
Video Compression
|
Camera title, Time, Video loss, Alarm, Motion detection, Recording |
Resolution
|
720P(1280×720), 960H(P:960×576/N:960×480) |
Video Quality Adjustment
|
Best/Fine/Normal |
Record Rate
|
720P(1280×720 200fps/240fps), 960H(P:960×576 200fps/N:960×480 240fps) |
Record Mode
|
Manual\Timer\Motion Detection\alarm |
Synchronous playback
|
4 Channel / 1Channel |
Remote Playback
|
4 Channel/ 1Channel |
Search Mode
|
ALL, Channel, Manual, Time, Date, Motion Detection |
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play |
Backup Mode
|
USB Device/Network |
Network interface
|
1 RJ45 10M/100M Adaptive Ethernet Interface |
Network Functions
|
HTTP, IPv4,IPv6, TCP/IP, SMTP, DHCP, DNS, PPPOE, DDNS,NTP,DST |
DDNS
|
3322, Dyndns,changeip,no-ip |
CMS
|
Support Windows XP /Windows Vista/Windows 7/Windows 8 |
Extra Stream
|
D1/CIF/QCIF(1~25fps) |
Smart Phone (Platform)
|
iPhone, ipad, Android ,Android pad |
HarddiskType
|
1 SATA Interface |
Hard Disk Storage
|
Up to 2TB Capacity |
Language
|
Support 19 languages (Chinese, English, polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Persian, Germany, France, Portugal, Turkey, Spain, Italy, Hungary, Romania, Korean) |
USB interface
|
2 USB 2.0 Interfaces |
Power Supply
|
DC12V/3A |
Working temperature
|
-10~55℃/10~90% |
