Camera |
Sensor |
1/2.8", 2 megapixel, progressive scan, low illumination CMOS |
Lens |
4.7 ~ 103 mm (22x optical zoom) |
Angle of view(H) |
59.7° (wide) ~ 3.4° (tele) |
Iris |
Auto/Manual; F1.6 ~ F3.2 |
Shutter |
Auto/Manual; shutter time: 1/6 s ~ 1/8000 s |
Min. Illumination |
Color: 0.03 Lux (F1.6, 50IRE) Black & White: 0.01Lux (F1.6, 50IRE) |
S/N |
>52dB |
Day/Night |
IR-cut filter with auto switch (ICR) |
Video |
Max. Resolution |
1920 × 1080 |
Video Compression |
H.264,MJPEG |
Frame Rate |
1080P (1920*1080): Max. 30 fps; 720P (1280*720): Max. 30 fps; D1 (720*576): Max. 25 fps |
Video Streaming |
Triple |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 8 areas |
Digital Zoom |
Supported |
Audio |
Audio Compression |
G.711 |
Two-way audio |
Supported |
Storage |
Edge Storage |
SD, up to 64 GB |
Network |
Protocols |
L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP, NTP,FTP,HTTP,SNMP,SIP |
Compatible Integration |
ONVIF, IMOS,API |
Pan & Tilt |
Pan Range |
360° (endless) |
Pan Speed |
0.1°/s ~ 400°/s |
Preset speed: 540°/s |
Tilt Range |
–1° ~ +90° (auto reverse) |
Tilt Speed |
0.1° ~ 240°/s |
Preset speed: 400°/s |
Number of Preset |
255 |
Patrol |
Up to 16 patrols, up to 32 presets per patrol Note: The total number of patrols and patterns is 16. |
Pattern |
Up to 16 patterns, with the total recording time not less 15 minutes per pattern |
Interface |
Audio I/O |
audio cable |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O |
2 / 1 |
Serial Port |
1 RS485 |
Network |
1 RJ45 10M/100M Base-TX Ethernet |
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
General |
Power |
24 V AC, 24 V DC, or PoE(IEEE802.3at) |
Power consumption: 9 ~ 13 W |
Dimensions (Ø x H) |
Ø195 x 263 mm (Ø7.7” x 10.4”) |
Weight |
3.2 kg (7.1 lb) |
Working Environment |
–20°C ~ +50°C (-4°F ~ 122°F), Humidity ≤ 90% RH(non-condensing) |
