Camera |
Sensor |
1/2.8", 2 megapixel, progressive scan, CMOS |
Lens |
4.5 ~ 148.5 mm (33x optical zoom) |
Angle of view(H) |
62° (wide) ~ 3.44° (tele) |
Iris |
Auto/Manual, F1.6 ~ F4.4 |
Shutter |
Auto/Manual, 1/6s ~ 1/8000s |
Min. Illumination |
Color: 0.02 Lux (F1.6, AGC ON) 0 Lux with IR on |
S/N |
>52dB |
Day/Night |
IR-cut filter with auto switch (ICR) |
Video |
Max. Resolution |
1920 × 1080 |
Video Compression |
H.264,MJPEG |
Frame Rate |
1080P (1920×1080): Max. 30 fps |
Video Streaming |
Triple |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 8 areas |
Digital Zoom |
Supported |
Auto tracking |
Scene |
4, scene switching plan configurable |
Detection |
Line cross, enter/leave area, intrusion |
Smart Function |
Auto tracking, snapshot when a moving object breaks the rules |
Audio |
Audio Compression |
G.711 |
Two-way audio |
Supported |
Storage |
Edge Storage |
Micro SD, up to 128 GB |
Network |
Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, SIP, QoS |
Compatible Integration |
ONVIF, API |
Pan & Tilt |
Pan Range |
360° |
Pan Speed |
0.1°/s ~ 240°/s |
Preset speed: 300°/s |
Tilt Range |
–15° ~ +90° (auto reverse) |
Tilt Speed |
0.1° ~ 160°/s |
Preset speed: 240°/s |
Number of Preset |
256 |
Patrol |
Preset patrol, route patrol, recorded patrol |
Home Position |
Supported |
Drag-to-Zoom |
Supported |
Interface |
Audio I/O |
Audio interface |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O |
2 / 1 |
Serial Port |
1 RS485 |
Network |
100M/1000M Base-FX adaptive SFP single mode (FC) 10M/100M/1000M Base-TX adaptive Ethernet 1+1 share mode |
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
General |
Power |
24 V AC±25% (Default), 24 V DC |
Power consumption: 17 ~54 W |
Dimensions (Ø x H) |
Ø227 x 359.4 mm (Ø8.9” x 14.2”) |
Weight |
5.4 kg (11.9 lb) |
Working Environment |
–40°C ~ +70°C (-40°F ~ 158°F), Humidity ≤ 95% RH(non-condensing) |
Ingress Protection |
IP66 |
