Spesifikasi :
Camera
Image Sensor
1/3-type 760H Super HAD CCD II
Image Sensor (Number of Effective Pixels)
Approx. 0.44 Megapixels
Signal System
PAL
Minimum Illumination (50 IRE)
Color: 0.15 lx (F1.2 AGC ON) B/W: 0.10 lx (F1.2 AGC ON)
Minimum Illumination (30 IRE)
Color: 0.08 lx (F1.2 AGC ON) B/W: 0.03 lx (F1.2 AGC ON)
S/N Ratio
More than 55 dB (AGC Off)
Gain
Auto (on/off)
Shutter Speed
Fixed (1/50s)
Sync System
Internal/AC line lock selectable
White Balance
ATW (2000K to 10000K) ATW-pro (2500K to 6000K)
Lens
Vari-focal type
Powered Zoom
No
Zoom Ratio
Optical 3.7x
Powered Focus
Horizontal Viewing Angle
99.5° to 27.4°
Swivel Range
350°
Focal Length
f = 2.8 mm to 10.5 mm
F-Number
F1.2 to F2.6
Minimum Object Distance
300 mm
Horizontal Resolution
540 TVL
Pan/Tilt Angle
355°/±77°
Infrafed Illuminators
Camera Features
Day/Night
Yes (Electrical D/N)
Image Enhancement
Yes (ATR-Lite, on/off), Yes (iBLC, on/off)
Noise Reduction
Yes (2DNR, on/off)
Interface
Analog Monitor Output
VBS: 1.0Vp-p
General
Power Requirements
AC24V ±10%, DC12V ±10%
Power Consumption
1.5 W max.
Operating Temperature
-10°C to +50°C 14°F to 122°F
Storage Temperature
-40°C to +60°C -40°F to +140°F
Operating Humidity
20% to 80%
Storage Humidity
20% to 95%
Vandal Resistant
Dimensions *1
φ121.6 x 86.5 mm φ4 7/8 x 3 1/2 inches
Mass
320 g 11.3 oz
Safety Regulations
EN55022(Class A)+EN50130-4 EN55022(Class A)+EN55024 AS/NZS CISPR22 Class A IEC60065 GOST-R IEC60065 compliance
Ingress Protection
Supplied Accessories
Operating instructions (1) Template (1)
