Image Sensor
|
1/2.7" 2M CMOS |
Total Pixels
|
1,952(H) x 1,092(V) |
Effective Pixels
|
1,920(H) x 1,080(V) |
Scanning System
|
Progressive scan |
Min.Illumination
|
Color : 0.25Lux (F2.1) B/W : 0Lux (IR LED on) |
S/N Ratio
|
52dB (AGC off, Weight on) |
Video Output
|
BNC (AHD, CVBS selectable) |
Resolution
|
1920 x 1080 |
Max. Framerate
|
30fps@1080p, 30fps@720p |
Focal length
|
4mm fixed |
Max. Aperture Ratio
|
F2.1 |
Min. Object Distance
|
0.5m (1.64ft) |
Focus Control
|
Manual |
Lens Type
|
Fixed |
Mount Type
|
Board-in type |
Pan / Tilt / Rotate Range
|
0° ~ 350° / 0° ~ 67° / 0° ~ 355° |
On Screen Display
|
English, Japanese, Spanish, French, Portuguese, Korean, German, Italian, Russian, Polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish |
Camera Title
|
Off / On (Displayed 15 characters) |
Day/Night
|
Auto (ICR) / Color / B/W |
Backlight Compensation
|
Off / User BLC / HLC |
Wide Dynamic Range
|
DWDR |
DNR
|
SSNRIV (Off / On) |
Defog
|
Off / Auto / Manual |
Motion Detection
|
Off / On (4 zones) |
Privasi masking
|
Off / On (4 zones rectangle) |
Gain Control
|
Off / Low / Middle / High |
White Balance
|
ATW / Outdoor / Indoor / Manual / AWC (1,800K° ~ 10,500K°) |
Electronic Shutter
|
1sec ~ 1/12,000sec |
Reverse
|
Off / H-Rev / V-Rev / HV-Rev |
Profile
|
Basic, Day & Night, Backlight, Indoor, User |
Remote Control Interface
|
Coaxial control |
Protocol Support
|
Coax : NTSC/PAL - Samsung CCVC, Pelco-C (Coaxitron), AHD - ACP (AHD Coax Protocol) |
IR distance
|
20m (65.62ft) |
Transmission Distance 5C2V (75ohm)
|
500m (1,640.42ft) (75-5 coaxial cable) |
Operating Temperature
|
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Input Voltage / Current
|
12V DC ±10% |
Power Consumption
|
Max. 4.2W |
Color / Material
|
vory / Plastic |
Dimensions (WxH)
|
Ø110.0 x 86.0mm (Ø4.33" x 3.39") |
Weight (approx.)
|
242g (0.53 lb) |
