Video Input
|
16 Composite video 0.5-1 Vp-p, 75 ohm automatic termination |
Video Resolution
|
NTSC : 704 x 480 / PAL : 704 x 576 |
Frame Rate
|
NTSC : 480fps / PAL : 400fps |
Resolution
|
NTSC : 704 x 480 / PAL : 704 x 576 |
Multi Screen Display
|
1 / 4 / 6 / 8 / 9 / 13 / 16 / PIP |
Embedded
|
Linux |
Compression
|
H.264 |
Record Rate
|
NTSC : Up to 120fps@704 x 480 / PAL : Up to 100fps@704 x 576 NTSC : Up to 240fps@704 x 240 / PAL : Up to 200fps@704 x 288 NTSC : Up to 480fps@352 x 240 / PAL : Up to 400fps@352 x 288 |
Recording Mode
|
NTSC : Manual, Schedule (Continuous / Event), Event (Pre / Post), Time lapse (0.9 / 1.9 / 3.8 / 7.5 / 15 / 30fps) PAL : Manual, Schedule (Continuous / Event), Event (Pre / Post), Time lapse (0.8 / 1.6 / 3.1 / 6.2 / 12.5 / 25fps |
Overwrite Modes
|
Continuous |
Pre-alarm Recording
|
Up to 30sec (5, 10, 20, 30sec) |
Post-alarm
|
Up to 6hour (5,10, 20, 30sec, 1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour) |
Search & Playback (Search)
|
Date/Time, Event, Back up, Pos, Motion (*All search include preview function) |
Search & Playback Functions
|
Fast forward / backward, Slow forward / backward, Step forward / backward |
Transmission Speed
|
CIF 480/400fps |
Bandwidth
|
Up to 8Mbps, Unlimited (8M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps |
Bandwidth Control
|
Selectable |
Stream
|
H.264 (4CIF / 2CIF / CIF selectable) |
Max. Remote Users
|
Search 3 / Live unicast 10 / Live multicast 20 |
Protocol Support
|
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP |
Monitoring
|
NET-i Viewer SmartViewer, Webviewer |
Smart Phone (Platform)
|
Android, iOS |
Protocol Support
|
RTSP/RTP (UDP), CGI, HTTP |
Transmission Speed
|
Wi-Fi : CIF Max. 4fps (Single channel) / CIF Max. 4fps (Quad channel) 3G : CIF Max. 4fps (Single channel) / CIF Max. 4fps (Quad channel) |
Max. Remote Users
|
Live 1 |
Stream
|
Up to 5 SATA HDDs |
Storage (External HDD)
|
Up to 2 expansion bay (up to 4 HDD each) |
Storage (DVD Writer)
|
YES |
Storage (USB)
|
3 USB ports |
Storage (File Format)
|
AVI, BU (DVR player), EXE (Include player) |
Password Protection
|
1 Admin, 10 Group, 20 User per 1 group, User can be assigned authority for function |
Data Authentication
|
Watermark |
Monitors (VGA)
|
1 VGA (800 x 600, 1024 x 768, 1280 x 1024) |
Monitors (HDMI)
|
480p / 720p / 1080p resolution |
Monitors (Main Composite)
|
1 BNC (1 Vp-p, 75 ohm) |
Monitors (Spot Composite)
|
Digital spot (1 BNC, 1 Vp-p, 75 ohm), support multi screen and camera title |
Monitors (Loop Outputs)
|
16 |
Audio I/O
|
16CH line in (Built-in 4CH, option : audio extension cable) / 1CH line out |
Audio Compression
|
ADPCM |
Audio Sampling Rate
|
16KHz |
Alarm I/O
|
Terminal 16 inputs (NO/NC) / Terminal 4 relay outputs (NO/NC), Rating : 30V DC / 2A, 125V AC / 0.5A |
Alarm (Remote Notification)
|
Notification via e-mail |
Ethernet
|
1 RJ-45 (10/100/1000 Base-T) |
Serial Interface
|
RS-232/RS-485 for PTZ, Samsung system keyboard |
Connections (USB)
|
USB 2.0, 3 ports |
eSATA
|
2 External SATA ports |
Application Support
|
Mouse, Remote controller |
Protocol Support
|
Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD, DIAMOND, ERNA, KALATEL, VCL TP, Vicon PTZ control via coaxial cable [Samsung CCVC, Pelco-C (Coaxitron)] |
Input Voltage / Current
|
100 ~ 240V AC ±10%, 50/60Hz, Autoranging |
Power Consumption (±10%)
|
Max. 60W (With 1x HDD) |
Operating Temperature / Humidity
|
+0°C ~ +40°C (+32°F ~ +104°F) / 20% ~ 85% RH |
Dimensions (mm)
|
440.0 x 88.0 x 426.8mm (17.32" x 3.46" x 16.80") |
Weight
|
Approx. 7.5Kg (16.53 lb) With hard disks |
Rack Mounts
|
2ea |
Language
|
Korean, Japanese, Chinese, English, French, German, Spanish, Italian, Russian, Polish, Czech, Turkish, Netherlands, Portuguese, Swedish, Danish, Thailandais, Rumanian, Serbian, Croatian, Hungarian, Greek (22 Language) |
