Video Input
|
CVBS : 1.0 Vp-p / 75 Ω composite, NTSC/PAL auto detection |
De-interlacing Filter
|
Built-in |
Alarm Triggers
|
Motion detection, Video loss |
Remote Control
|
RS-485/422 |
RS-485 Protocol
|
Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch |
Ethernet
|
RJ-45 (10/100BASE-T) |
Video Compression
|
H.264 / MPEG4 / MJPEG |
Resolution
|
704 x 480, 640 x 480, 352 x 240, 320 x 240 |
Max. Framerate
|
30fps |
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
Bitrate Control
|
H.264, MPEG-4 : CBR or VBR, MJPEG : VBR |
Streaming Capability
|
Multiple streaming (Up to 10 profiles) |
IP
|
IPv4, IPv6 |
Protocol Support
|
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS |
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log |
Streaming Method
|
Unicast / Multicast |
Max. User Access
|
10 users at unicast mode |
ONVIF
|
Yes |
Web Viewer
|
Supported OS : Windows XP / VISTA / 7, MAC OS Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari |
Central Management Software
|
NET-i viewer |
Operating Temperature
|
-10°C ~+50°C (+14°F ~ +122°F) / 20% ~ 80% RH |
Input Voltage / Current
|
PoE (IEEE802.3af), 12V DC |
Power Consumption (±10%)
|
Max. 3.2W |
Color / Material
|
White / Mold, Silver / Press |
Dimensions (mm)
|
43.0 x 29.0 x 95.5mm (1.69" x 1.41" x 3.76"), Connector included |
Weight
|
115g (0.25 lb) |
