Brand: Samsung Wisenet

Samsung SNV-7084R

Rp 11.399.000

tidak termasuk pengiriman

• Max 3M (2048 x 1536), Full HD(1080p) resolution
• 30fps @ 2048 x 1536 / 60fps @ 1920 x 1080
• SSLE(Samsung Super Light Enhancer) : 0.1Lux
Min.Illumination 0Lux (IR Distance 25m)
• Enhanced WDR (120dB)/ 30fps @3MP WDR
• Improved Network Bandwidth :3.0Mbps
• Simple Focus, P-Iris
• Built-in 3~ 8.5mm(2.8x) Motorized Varifocal lens
• Face/Motion/Audio Detection
• UPnP (Auto Port Forwarding)
• Defog, DIS support
• H.264 & MJPEG dual codec
• Multi-crop streaming
• Day & Night(ICR), SD/SDHC/SDXC Memory slot
• PoE, IP66/IK10 Grade

Overview
Specifications
Contact Us

SAMSUNG SNV-7084R VANDAL RESISTANT NETWORK IR DOME CAMERA

Jual CAMERA CCTV SAMSUNG SNV-7084R. SAMSUNG SNV-7084R Merupakan CCTV yang bias di bilang canggih karena SAMSUNG SNV-7084R mengusung teknologi yang modern dan mempunyai spesifikasi yang mempuni. Contoh dari fitur ini adalah dari segi resolusi memiliki 3 mega pixel, membuat gambar yang di hasilkan bersih dan jernih, CAMERA CCTV SAMSUNG SNV-7084R ini biasa di pakai di pertokoan, perkantoran atau pun instansi-instansi besar di Indonesia.

DOME CAMERA SAMSUNG SNV-7084R terkenal di dunia dengan spesifikasi nya yang tinggi dan ada banyak fitur-fitur di dalam SAMSUNG SNV-7084R, Contohnya seperti alarm sudah menggunakan fitur Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input dan fitur keamanan sudah menggunakan HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication. CAMERA CCTV SAMSUNG SNV-7084R ini bisa memantau aktivitas orang-orang yang mencurigakan dari dalam ruangan ataupun dari luar.

Fitur CAMERA CCTV SAMSUNG SNV-7084R

30fps@2,048x1,536/60fps@1,920x1,080
Simplefocus(MotorizedVF),P-Iris
Day&Night(ICR),EnhancedDIS,Defog
3Mreal-timeWDR(Max.120dB)
Color:0.1Lux(F1.2,50IRE)
B/W:0Lux(IRLEDon)
Built-inSD/SDHC/SDXCmemoryslot
Multi-cropstreaming
IP66/IK10

JakartaCCTV adalah distributor kamera CCTV dan IP Camera terbesar di Indonesia. Dengan kelengkapan produk kamera CCTV dan IP Kamera yang dimiliki, jakartaCCTV dapat memberikan solusi bagi anda yang ingin memasang kamera CCTV murah di jakarta, bisa memantau sistem keamanan menggunakan CCTV diantaranya perkantoran, pertokoan, pabrik, apartemen dll. Tidak hanya itu anda bisa membeli kamera CCTV dengan berbagai model yang telah kami sediakan dan anda akan di berikan tips cara membeli CCTV yang murah dan aman dari kami jakartaCCTV, Tidak hanya itu pembelian CCTV bisa di lakukan secara online bagi yang tinggal di Jakarta ataupun kota-kota lain nya.

Spesifikasi produk

Imaging Device	1/2.8" PS Exmor 3.2M CMOS
Total Pixels	2.065(H)x1.565(V)
Effective Pixels	2.065(H)x1.553(V)
Scanning System	Progressive scan
Min.Illumination	Color : 0.3Lux (1/30sec, F1.2, 50IRE), 0.005Lux (2sec, F1.2, 50IRE)
S/N RATIO	50dB
Video Output	CVBS : 1.0 Vpp / 75 Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type
Focal Lenght (Zoom Ratio)	3 ~ 8.5mm (2.8x) motorized varifocal
Max. Aperture Ratio	F1.2
Angular Field of View	H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele)
Min. Object Distance	0.5m (1.64ft)
Focus Control	Simple focus / Manual, Remote control via network, Button control (Manual, Simple focus)
Lens / Mount Type	DC auto iris / Board-in type
Pan / Tilt / Rotate Range	0° ~ 354° / 0° ~ 67° / 0° ~ 355°
IR LED	12ea
Viewable Length	25m (82.02ft)
Camera Title	Off / On (Displayed up to 15 characters)
Day/Night	Auto (ICR) / Color / B/W / External / Schedule
Backlight Compensation	Off / BLC / WDR
Wide Dynamic Range	120dB
Contrast Enhancement	SSDR (Off / On)
Digital Noise Reduction	SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization	Off / On
Defog	Off / Auto / Manual
Motion Detection	Off / On (4 zones with 4 points polygonal)
Privasi masking	Off / On (32 zones with 4 points of polygonal)
Gain Control	Off / Low / Medium / High / Manual
White Balance	ATW / AWC / INDOOR / OUTDOOR / MANUAL / AWB
Electronic Shutter Speed	Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
Flip / Mirror	Off / On
Intelligent Video Analytics	Tampering,Virtual Line,Enter/Exit ,Appear/Disappear,Face Detection With MetaData
Alarm I/O	Input 1ea / Output 1ea
Alarm Triggers	Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input
Alarm Events	File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP, Local storage (SD/SDHC/SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output
Ethernet	RJ-45 (10/100BASE-T)
Video Compression Format	H.264 (MPEG-4 part 10/AVC), MJPEG
Resolution	2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Max. Framerate	H.264 : Max. 30fps@2048 x 1536, Max 60fps@the other resolutions MJPEG : Max. 10fps@2048 x 1536 Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Smart Codec	Manual mode (Area-based : 5ea), Face detection mode
Video Quality Adjustment	H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method	H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability	Multiple streaming (Up to 10 profiles)
Audio Input	Selectable (Mic in / Line in), Max output level : 1 Vrms Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Output	Line out (3.5mm mono jack), Max output level : 1 Vrms
Audio Compression Format	G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication	Bi-directional audio
IP	IPv4, IPv6
Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
Streaming Method	Unicast / Multicast
Max. User Access	15 users at unicast mode
Edge Storage	micro SD/SDHC/SDXC Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded NAS (Network Attached Storage
Application Programming Interface	ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2
Webpage Language	English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish
Web Viewer	Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11 ~ 8) Mozilla Firefox (Ver. 19 ~9) * Windows only Google Chrome (Ver. 25 ~ 15) * Windows only Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only
Central Management Software	SmartViewer, SSM
Operating Temperature / Humidity	24V AC : -40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH 12V DC, PoE : -20°C ~ +55°C (-4°F ~ +131°F) / Less than 90% RH *Start up should be done at above -10°C (+14°F)
Storage Temperature / Humidity -	-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection / Vandal Resistance	IP66 / IK10
Input Voltage / Current	24V AC, 12V DC, PoE (IEEE802.3af class 3)
Power Consumption (±10%)	Max. 10.5W (12V DC), Max. 11.5W (PoE), Max. 12.0W / 15.0W (24V AC, Heater off / on) * Heater works at AC power input only
Color / Material	Ivory / Aluminium
Dimensions (WxH)	135.2 x 54.3 x 124.5mm (5.32" x 2.14" x 4.9")
Weight	975g (2.15 lb)

Namamu *

Email Anda *

Pertanyaan *

SAMSUNG SNV-7084R VANDAL RESISTANT NETWORK IR DOME CAMERA

Fitur CAMERA CCTV SAMSUNG SNV-7084R

30fps@2,048x1,536/60fps@1,920x1,080
Simplefocus(MotorizedVF),P-Iris
Day&Night(ICR),EnhancedDIS,Defog
3Mreal-timeWDR(Max.120dB)
Color:0.1Lux(F1.2,50IRE)
B/W:0Lux(IRLEDon)
Built-inSD/SDHC/SDXCmemoryslot
Multi-cropstreaming
IP66/IK10

Spesifikasi produk

Imaging Device	1/2.8" PS Exmor 3.2M CMOS
Total Pixels	2.065(H)x1.565(V)
Effective Pixels	2.065(H)x1.553(V)
Scanning System	Progressive scan
Min.Illumination	Color : 0.3Lux (1/30sec, F1.2, 50IRE), 0.005Lux (2sec, F1.2, 50IRE)
S/N RATIO	50dB
Video Output	CVBS : 1.0 Vpp / 75 Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type
Focal Lenght (Zoom Ratio)	3 ~ 8.5mm (2.8x) motorized varifocal
Max. Aperture Ratio	F1.2
Angular Field of View	H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele)
Min. Object Distance	0.5m (1.64ft)
Focus Control	Simple focus / Manual, Remote control via network, Button control (Manual, Simple focus)
Lens / Mount Type	DC auto iris / Board-in type
Pan / Tilt / Rotate Range	0° ~ 354° / 0° ~ 67° / 0° ~ 355°
IR LED	12ea
Viewable Length	25m (82.02ft)
Camera Title	Off / On (Displayed up to 15 characters)
Day/Night	Auto (ICR) / Color / B/W / External / Schedule
Backlight Compensation	Off / BLC / WDR
Wide Dynamic Range	120dB
Contrast Enhancement	SSDR (Off / On)
Digital Noise Reduction	SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization	Off / On
Defog	Off / Auto / Manual
Motion Detection	Off / On (4 zones with 4 points polygonal)
Privasi masking	Off / On (32 zones with 4 points of polygonal)
Gain Control	Off / Low / Medium / High / Manual
White Balance	ATW / AWC / INDOOR / OUTDOOR / MANUAL / AWB
Electronic Shutter Speed	Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
Flip / Mirror	Off / On
Intelligent Video Analytics	Tampering,Virtual Line,Enter/Exit ,Appear/Disappear,Face Detection With MetaData
Alarm I/O	Input 1ea / Output 1ea
Alarm Triggers	Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input
Alarm Events	File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP, Local storage (SD/SDHC/SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output
Ethernet	RJ-45 (10/100BASE-T)
Video Compression Format	H.264 (MPEG-4 part 10/AVC), MJPEG
Resolution	2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Max. Framerate	H.264 : Max. 30fps@2048 x 1536, Max 60fps@the other resolutions MJPEG : Max. 10fps@2048 x 1536 Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Smart Codec	Manual mode (Area-based : 5ea), Face detection mode
Video Quality Adjustment	H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method	H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability	Multiple streaming (Up to 10 profiles)
Audio Input	Selectable (Mic in / Line in), Max output level : 1 Vrms Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Output	Line out (3.5mm mono jack), Max output level : 1 Vrms
Audio Compression Format	G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication	Bi-directional audio
IP	IPv4, IPv6
Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
Streaming Method	Unicast / Multicast
Max. User Access	15 users at unicast mode
Edge Storage	micro SD/SDHC/SDXC Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded NAS (Network Attached Storage
Application Programming Interface	ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2
Webpage Language	English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish
Web Viewer	Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11 ~ 8) Mozilla Firefox (Ver. 19 ~9) * Windows only Google Chrome (Ver. 25 ~ 15) * Windows only Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only
Central Management Software	SmartViewer, SSM
Operating Temperature / Humidity	24V AC : -40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH 12V DC, PoE : -20°C ~ +55°C (-4°F ~ +131°F) / Less than 90% RH *Start up should be done at above -10°C (+14°F)
Storage Temperature / Humidity -	-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection / Vandal Resistance	IP66 / IK10
Input Voltage / Current	24V AC, 12V DC, PoE (IEEE802.3af class 3)
Power Consumption (±10%)	Max. 10.5W (12V DC), Max. 11.5W (PoE), Max. 12.0W / 15.0W (24V AC, Heater off / on) * Heater works at AC power input only
Color / Material	Ivory / Aluminium
Dimensions (WxH)	135.2 x 54.3 x 124.5mm (5.32" x 2.14" x 4.9")
Weight	975g (2.15 lb)
