Imaging Device
|
1/2.8" 2.38M CMOS |
Total Pixels
|
1,952(H) x 1,116(V), 2.18M pixels |
Effective Pixels
|
1,944(H) x 1,104(V), 2.14M pixels |
Scanning System
|
Progressive scan |
Min.Illumination
|
Color : 0.3Lux (1/30sec, F1.6, 50IRE, AGC high) , 0.005Lux (2sec, F1.6, 50IRE, AGC high) B/W : 0.03Lux (1/30sec, F1.6, 50IRE, AGC high), 0.0005Lux (2sec, F1.6, 50IRE, AGC high) Color : 0.15Lux (1/30sec, F1.6, 30IRE), 0.0025Lux (2sec, F1.6, 30IRE) B/W : 0.015Lux (1/30sec, F1.6, 30IRE), 0.00025Lux (2sec, F1.6, 30IRE) |
S/N RATIO
|
50dB |
Video Output
|
CVBS : 1.0 Vpp / 75 Ω composite, 704 x 480(N), 704 x 576(P), for installation |
Focal Lenght (Zoom Ratio)
|
4.44 ~ 142.6mm (Optical 32x) |
Max. Aperture Ratio
|
F1.6(Wide) / F4.4(Tele) |
Angular Field of View
|
H : 62.8 ̊(Wide) ~ 2.23 ̊(Tele) / V : 36.8 ̊(Wide) ~ 1.26 ̊(Tele) |
Min. Object Distance
|
Wide : 1.5m (4.92ft), Tele : 2m (6.56ft) |
Focus Control
|
Auto / Manual / One Push |
Lens Type
|
Manual / DC auto iris |
Mount Type
|
Board type |
Pan Range
|
360° Endless |
Pan Speed
|
Preset : 700 ̊/sec, Manual : 0.024 ̊/sec ~ 120 ̊/sec |
Tilt Range
|
210 ̊ (-15 ̊ ~195 ̊ ) |
Tilt Speed
|
Preset : 700 ̊/sec, Manual : 0.024 ̊/sec ~ 120 ̊/sec |
Sequence
|
Preset (255ea), Swing, Group (6ea), Trace, Tour (1ea), Auto run, Schedule |
Preset Accuracy
|
±0.2 ̊ |
Azimuth
|
Yes (E / W / S / N / NE / NW / SE / SW) |
Camera Title
|
Off / On (Displayed up to 45 characters) |
Day/Night
|
Auto(ICR) / Color / B/W |
Backlight Compensation
|
Off / BLC |
Wide Dynamic Range
|
120dB |
Contrast Enhancement
|
SSDR (Off / On) |
Noise Reduction
|
SSNR III (2D+3D noise filter) (Off / On) |
Digital Image Stabilization
|
Off / On |
Defog
|
Off / Auto / Manual |
Motion Detection
|
Off / On (4ea, Rectanglular zones) |
Privasi masking
|
Off / On (32 zones of rectangle zone) with zoom threshold mosaic option |
Gain Control
|
Low / Middle / High / Off |
White Balance
|
ATW / Indoor / Outdoor / AWC / Manual / Mercury |
Electronic Shutter
|
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
Digital Zoom
|
16x |
Flip / Mirror
|
Off / On |
Intelligent Video Analytics
|
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection |
Alarm I/O
|
input 4ea / output 2ea ( relay) |
Remote Control
|
RS-485 |
RS-485 Protocol
|
Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch |
Alarm Triggers
|
Motion detection, Tampering, Audio detection, Face detecton, Video analytics, Alarm input, Network disconnection |
Alarm Events
|
File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP, Local storage (SD/SDHC/SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output |
Ethernet
|
RJ-45 (10/100BASE-T) |
Video Compression
|
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution
|
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Max. Framerate
|
H.264 : Max. 60fps at all resolutions MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max.30fps |
Smart Codec
|
Yes |
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
Bitrate Control
|
H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability
|
Multiple streaming (Up to 10 profiles) |
Audio Input
|
Selectable (Mic in / Line in : SNF-8010/8010VM), Built-in Mic : SNF-8010 Supply voltage : 2.5V DC (4mA), Input impedance : approx 2K ohm |
Audio Output
|
Line out (3.5mm mono jack), Max output level : 1 Vrms |
Audio Compression
|
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Audio Communication
|
Bi-directional audio |
IP
|
IPv4, IPv6 |
Protocol Support
|
CP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
Streaming Method
|
Unicast / Multicast |
Max. User Access
|
10 users at unicast mode |
Edge Storage
|
micro SD/SDHC/SDXC (64GB) - Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded, NAS (Network Attached Storage) |
Application Programming Interface
|
ONVIF profile S, SUNAPI (HTTP API), SVNP 2.0, Samsung camera application platform |
Webpage Language
|
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
Web Viewer
|
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
Central Management Software
|
SmartViewer, SSM |
Operating Temperature
|
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Storage Temperature
|
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
Input Voltage / Current
|
24V AC ±10%, PoE+ (IEEE802.3af, Class4) |
Power Consumption (±10%)
|
Max. 20W |
Color / Material
|
Ivory / Plastic + Metal |
Dimensions (mm)
|
Ø152.0 x 218.0mm (Ø5.98" x 8.58") |
Weight
|
1.8 Kg |
