Imaging Device
|
1/4" 1.3M CMOS |
|
Total Pixels
|
1.392(H)x1.076(V),1.49M pixels |
|
Effective Pixels
|
1.368(H)x1.049(V),1.43Mpixels |
|
Scanning System
|
Progressive scan |
|
Min.Illumination
|
Color : 0.5Lux (F1.4, 50IRE), 0.3Lux (F1.4, 30IRE) B/W : 0.01Lux (F1.4, 50IRE), 0.006Lux (F1.4, 30IRE) |
|
S/N RATIO
|
50dB |
|
Video Output
|
CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation |
|
Focal Lenght (Zoom Ratio)
|
3.5 ~ 150.5mm (Optical 43x) |
|
Max. Aperture Ratio
|
F1.4(Wide) / F4.9(Tele) |
|
Angular Field of View
|
H : 53.92˚(Wide) ~ 1.396˚(Tele) / V : 44.08˚(Wide) ~ 1.12˚(Tele) |
|
Min. Object Distance
|
Wide : 1.5m (4.92ft), Tele : 2m (6.56ft) |
|
Focus Control
|
Auto / Manual / One Push |
|
Lens Type
|
DC auto iris |
|
Mount Type
|
Board type |
|
Pan Range
|
360° Endless |
|
Pan Speed
|
Preset : 700 ̊/sec, Manual : 0.024 ̊/sec ~ 120 ̊/sec |
|
Tilt Range
|
210 ̊ (-15 ̊ ~195 ̊ ) |
|
Tilt Speed
|
Preset : 700 ̊/sec, Manual : 0.024 ̊/sec ~ 120 ̊/sec |
|
Preset Points
|
255ea |
|
Preset Accuracy
|
±0.2 ̊ |
|
Auto Tracking
|
Off / On |
|
Camera Title
|
Off / On (Displayed 15 characters) |
|
Day/Night
|
Auto(ICR) / Color / B/W |
|
Backlight Compensation
|
Off / User BLC / HLC / WDR |
|
Wide Dynamic Range
|
120dB |
|
Contrast Enhancement
|
SSDR (Off / On) |
|
Noise Reduction
|
SSNR III (2D+3D noise filter) (Off / On) |
|
Digital Image Stabilization
|
Off / On |
|
Defog
|
Off / Auto / Manual |
|
Motion Detection
|
Off / On (4ea, Rectanglular zones) |
|
Privasi masking
|
Off / On (32 zones of rectangle zone) |
|
Gain Control
|
Low / Middle / High / Off |
|
White Balance
|
ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium |
|
Electronic Shutter
|
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
|
Digital Zoom
|
16x |
|
Flip / Mirror
|
Off / On |
|
Intelligent Video Analytics
|
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection |
|
Alarm I/O
|
input 4ea / output 2ea ( relay) |
|
Remote Control
|
RS-485 |
|
RS-485 Protocol
|
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE |
|
Alarm Triggers
|
Motion detection, Tampering, Audio detection, Face detection, Video analytics, Alarm input, Network disconnection |
|
Alarm Events
|
File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP, Local storage (SD/SDHC/SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output |
|
Ethernet
|
RJ-45 (10/100BASE-T) |
|
Video Compression
|
H.264 (MPEG-4 part 10/AVC), MJPEG |
|
Resolution
|
1280 x 1024, 1280 x 720, 1024 x 768, 800 x 600, 640 x 480, 320 x 240 |
|
Max. Framerate
|
H.264 : Max. 60fps at all resolutions MJPEG : 1280 x 1024, 1280 x 720, 1024 x 768 : Max. 15fps 800 x 600, 640 x 480, 320 x 240 : Max. 30fps |
|
Smart Codec
|
Manual mode (Area-based : 5ea), Face detection mode |
|
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
|
Bitrate Control
|
H.264 : CBR or VBR, MJPEG : VBR |
|
Streaming Capability
|
Multiple streaming (Up to 10 profiles) |
|
Audio Input
|
Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
|
Audio Output
|
Line out (3.5mm mono jack), Max output level : 1 Vrms |
|
Audio Compression
|
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
|
Audio Communication
|
Bi-directional audio |
|
IP
|
IPv4, IPv6 |
|
Protocol Support
|
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, RTCP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
|
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
|
Streaming Method
|
Unicast / Multicast |
|
Max. User Access
|
15 users at unicast mode |
|
Edge Storage
|
SD/SDHC/SDXC (SNP-5340 : micro SD type, SNP-5340H : SD type) Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded NAS (Network Attached Storage) |
|
Application Programming Interface
|
ONVIF profile S, SUNAPI 2.0, SVNP 1.2 |
|
Webpage Language
|
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian |
|
Web Viewer
|
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 / 10.8 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 32), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 Only), 5.1.7) * Mac OS X only |
|
Central Management Software
|
SmartViewer, SSM |
|
Operating Temperature / Humidity
|
24V AC : -50°C ~ +55°C (-58°F ~ +131°F) / Less than ~ 90% RH PoE+ : -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH |
|
Storage Temperature
|
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
|
Ingress Protection
|
IP66 |
|
Vandal Resistance
|
IK10 |
|
Input Voltage / Current
|
24V AC ±10%, PoE+ (IEEE802.3at class3) |
|
Power Consumption (±10%)
|
Max. 24W (Heater off), Max. 65W (Heater on, 24V AC) |
|
Color / Material
|
Ivory / Plastic + Metal |
|
Dimensions (mm)
|
Ø223.4 x 293.6mm (Ø8.8" x 11.56") |
|
Weight
|
3.4Kg (7.5 lb) |
