Imaging Device
|
1/2.8" PS Exmor 3.2M CMOS |
Total Pixels
|
2.065(H)x1.565(V) |
Effective Pixels
|
2.065(H)x1.553(V) |
Scanning System
|
Progressive scan |
Min.Illumination
|
Color : 0.1Lux (F1.2, 50IRE), 0.01Lux (30fps, 1sec, 50IRE), B/W : 0.01Lux (F1.2, 50IRE) |
S/N RATIO
|
50dB |
Video Output
|
CVBS : 1.0 Vpp / 75 Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type |
Focal Lenght (Zoom Ratio)
|
3 ~ 8.5mm (2.8x) motorized varifocal |
Max. Aperture Ratio
|
F1.2 |
Angular Field of View
|
H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele) |
Min. Object Distance
|
0.5m (1.64ft) |
Focus Control
|
Simple focus / Manual, Remote control via network (Manual, Simple focus, Day & Night) |
Lens Type
|
Manual / DC auto iris |
Mount Type
|
Board type |
Pan Range
|
0° ~ 354° |
Tilt Range
|
0° ~ 67° |
Rotate Range
|
0° ~ 355° |
Camera Title
|
Off / On (Displayed up to 45 characters) |
Day/Night
|
Auto (ICR) / Color / B/W / External / Schedule |
Backlight Compensation
|
Off / BLC |
Wide Dynamic Range
|
120dB |
Contrast Enhancement
|
SSDR (Off / On) |
Noise Reduction
|
SSNR III (2D+3D noise filter) (Off / On) |
Digital Image Stabilization
|
Off / On |
Defog
|
Off / Auto / Manual |
Motion Detection
|
Off / On (4 zones with 4 points polygonal) |
Privasi masking
|
Off / On (32 zones with 4 points of polygonal) |
Gain Control
|
Low / Middle / High / Off |
White Balance
|
ATW / Outdoor / Indoor / Manual / AWC |
Electronic Shutter
|
Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec) |
Mirror
|
Off / On |
Intelligent Video Analytics
|
Tampering, Virtual line, Enter / Exit, Appear / Disappear, Audio detection, Face detection with metadata |
Alarm I/O
|
Input 1ea / Output 1ea |
Alarm Triggers
|
Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input |
Alarm Events
|
File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP Local storage (SD/SDHC/SDXC) recording at Network disconnected & Event (Alarm triggers), External output |
Ethernet
|
RJ-45 (10/100BASE-T) |
Video Compression
|
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution
|
2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Max. Framerate
|
H.264 : Max. 30fps@2048 x 1536, Max 60fps@the other resolutions MJPEG : Max. 10fps@2048 x 1536 Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Smart Codec
|
Built-in (Area-based : 5ea, Face detection mode) |
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
Bitrate Control
|
H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability
|
Multiple streaming (Up to 10 profiles) |
Audio I/O
|
Mic(Line)-in / Built-in mic selectable via UI, Line-out (Mono, 1Vrms) 2.5V DC (4mA) powered 2K Ohm |
Audio Compression
|
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Audio Communication
|
Bi-directional audio |
IP
|
IPv4, IPv6 |
Protocol Support
|
CP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
Streaming Method
|
Unicast / Multicast |
Max. User Access
|
15 users at unicast mode |
Memory Slot
|
Micro SD/SDHC/SDXC Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded |
Application Programming Interface
|
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
Webpage Language
|
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
Web Viewer
|
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11, 10, 9, 8), Mozilla Firefox (Ver. 19, 18, 17, 16, 15, 14, 13, 12, 11, 10, 9), Google Chrome (Ver. 25, 24, 23, 22, 21, 20, 19, 18, 17,16, 15), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
Central Management Software
|
SmartViewer |
Operating Temperature
|
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Storage Temperature
|
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
Input Voltage / Current
|
12V DC, PoE (IEEE802.3af class 3) |
Power Consumption (±10%)
|
Max. 9.6W (12V DC), Max. 11.6W (PoE) |
Color / Material
|
Ivory / Aluminium |
Dimensions (mm)
|
Ø132.1 x 107.6mm (Ø5.2" x 4.24") |
Weight
|
1Kg (2.2 lb) |
