Video |
Imaging Device |
1/2.9" 2M CMOS |
Total Pixels |
2,000(H) x 1,121(V) 2.24M pixels |
Effective Pixels |
1,984(H) x 1,105(V) 2.19M pixels |
Scanning System |
Progressive scan |
Min. Illumination |
Color : 0.11Lux (F1.4) B/W : 0Lux (IR LED on) |
S / N Ratio |
52dB (AGC off, Weight on) |
Video Output |
BNC (AHD, CVBS selectable) |
Resolution |
1920 x 1080 |
Max. Framerate |
30fps@1080p, 30fps@720p |
Lens |
Focal Length (Zoom Ratio) |
2.8 ~ 12mm (4.3x) varifocal |
Max. Aperture Ratio |
F1.4 |
Angular Field of View |
H : 103.8°(Wide) ~ 32.4°(Tele) / V : 53.7°(Wide) ~ 18.4°(Tele) / D : 121.9°(Wide) ~ 37.1°(Tele) |
Min. Object Distance |
0.5m (1.64ft) |
Focus Control |
Manual |
Lens Type |
DC auto iris |
Mount Type |
Board-in type |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0° ~ 350° / 0° ~ 67° / 0° ~ 355° |
Operational |
On Screen Display |
English, Japanese, Spanish, French, Portuguese, Korean, German, Italian,Russian, Polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish |
Camera Title |
Off / On (Displayed 15 characters) |
Day & Night |
Auto (ICR) / Color / B/W |
Backlight Compensation |
Off / User BLC / HLC |
Wide Dynamic Range |
DWDR |
Digital Noise Reduction |
SSNRIV (Off / On) |
Defog |
Off / Auto / Manual |
Motion Detection |
Off / On (4 zones) |
Privacy Masking |
Off / On (4 zones rectangle) |
Gain Control |
Off / Low / Middle / High / Very high |
White Balance |
ATW / Outdoor / Indoor / Manual / AWC (1,800K° ~ 10,500K°) |
Electronic Shutter Speed |
1sec ~ 1/12,000sec |
Reverse |
Off / H-Rev / V-Rev / HV-Rev |
Profile |
Basic, Day & Night, Backlight, Indoor, User, ITS |
Alarm |
(MD) output 1 |
Remote Control Interface |
Coaxial control |
Protocol |
Coax : NTSC/PAL - Samsung CCVC, Pelco-C (Coaxitron), AHD - ACP (AHD Coax Protocol) |
IR Distance |
20m (65.62ft) |
Video Transmission Distance |
500m (1,640.42ft) (75-5 coaxial cable) |
Environmental |
Operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Electrical |
Input Voltage / Current |
Dual (24V AC & 12V DC ±10%) |
Power Consumption |
Max. 4.2W |
Mechanical |
Color / Material |
Ivory / Plastic |
Dimensions (WxHxD) |
Ø119.8 x 98.5mm (Ø4.72" x 3.88") |
Weight |
304g (0.67 lb) |
