| Server |
| Image compression |
: |
JPEG (Motion JPEG), MPEG-4 |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 192 x 144 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion), MPEG4 |
| Frame rate |
: |
Max. 30 frames/sec (640 x 480, 320 x 240 or 192 x 144) |
| Security |
: |
User ID/password |
| Supported protocols |
: |
IPv4 / IPv6 Dual-Stack. IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnPTM, SMTP Authentication, RTP, RTSP, RTCP. IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP, RTCP |
| User access limit |
: |
Max. 30 simultaneous accesses |
| Buffered images |
: |
Approx. 250 images (320 x 240) •standard image quality •with time display |
| Image transfer method |
: |
SMTP, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Sensor, timer or motion detection |
Network Camera |
| Zoom |
: |
10x digital zoom (by area) |
| Viewing angle |
: |
49° horizontal (total 149°) 37° vertical (total 87°) |
| Pan (horizontal direction) |
: |
-50° up to +50° |
| Tilt (vertical direction) |
: |
-40° up to +10° |
| Revolving speed |
: |
Pan: max. 50°/sec; Tilt: max. 50°/sec |
| Sensor type |
: |
1/6 inch CMOS sensor, approx. 320,000 pixels |
| Lens focal point |
: |
Fixed (focal range: 0.3 m to ∞) |
| Lens brightness |
: |
F2.8 |
| Required light intensity |
: |
10 to 10,000 lux (in color night view mode: 3 to 10,000 lux) |
Audio |
| Audio communication |
: |
One-way communication |
| Audio compression |
: |
ADPCM 32 kbps |
| Audio bandwidth |
: |
300 Hz - 3.4 kHz |
| Audio input |
: |
Built-in microphone |
| Audio output |
: |
— |
Wireless |
| Standards |
: |
IEEE 802.11 b/g |
| Antenna |
: |
Diversity |
| Number of channel |
: |
11ch. (USA), 13ch. (Others) |
| Transmission speed |
: |
Up to 54 Mbps. |
| Security |
: |
SSID, WEP (64/128/152 bit), WPA-PSK (TKIP), WPA2-PSK (AES) |
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
— |
| Video output |
: |
— |
| Audio output |
: |
— |
| External Microphone Input |
: |
— |
| SD Memory Card slot |
: |
— |
General |
| Operating temperature |
: |
+5°C to +40°C (+41°F to +104°F) |
| Operating humidity |
: |
20% to 80% (no condensation) |
| Dimensions (H x W x D) |
: |
98 x 74 x 73 mm (3 7/8 x 2 15/16 x 2 7/8 inches) |
| Weight (only the unit) |
: |
210 g (0.46 lb) |
| Power supply (E) |
: |
Input: 220 - 240 V AC, output: 9 V DC |
| Power supply (CE) |
: |
Input: 100 - 240 V AC, output: 9 V DC |
| Power supply(US) |
: |
Input: 100 - 240 V AC, output: 9 V DC |
| Consumption |
: |
6.0 W |
