| Server |
| Image compression |
: |
JPEG (Motion JPEG), MPEG-4 |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 192×144 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion), MPEG-4 |
| Frame rate |
: |
Max. 30 frames/sec. (640 x 480*2, 320 x 240, 192 x 144) |
| Security |
: |
User ID / password, SSL |
| Supported protocols |
: |
IPv4/IPv6 Dual-Stack IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnP™, SMTP Authentication, RTP, RTSP*3, RTCP, HTTPS, SSL, TLS IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP*3, RTCP, HTTPS, SSL, TLS |
| User access limit |
: |
Max. 30 simultaneous users (Max. 10 users in SSL communication) |
| Buffered images |
: |
Approx. 250 images (320 x 240) •Standard image quality •with time display |
| Image transfer method |
: |
SMTP*5, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Alarm, timer or motion detection |
Network Camera |
| Zoom |
: |
10x digital zoom (by area) |
| Viewing angle |
: |
58° horizontal, 45° vertical |
| Sensor type |
: |
1/4 inch CMOS sensor, approx. 320,000 pixels |
| Lens focal point |
: |
Fixed (focal range: 0.3 m to ∞) |
| Lens brightness |
: |
F2.8 |
| Required light intensity |
: |
5 to 10,000 lux (in color night view mode : 3 to 10,000 lux ) |
Audio |
| Audio communication |
: |
One-way communication |
| Audio compression |
: |
ADPCM 32 kbps |
| Audio bandwidth |
: |
300 Hz – 3,4 kHz |
| Audio input |
: |
Built-in microphone |
Wireless |
Not Available
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
Input: 1 |
General |
| Operating temperature |
: |
+5°C to +40°C (+41°F to +104°F) |
| Operating humidity |
: |
20% to 80% (no condensation) |
| Dimensions (H x W x D) |
: |
85 x 85 x 27 mm (3 3/8 x 3 3/8 x 1 1/16 inches) |
| Weight (only the unit) |
: |
100 g (0.22 lb) |
| Power supply (CE) |
: |
Input: 100-240 V AC, output: 9 V DC |
| Consumption |
: |
2.8 W |
