| Server |
| Image compression |
: |
JPEG (Motion JPEG), MPEG-4 |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 192 x 144 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion), MPEG-4 |
| Frame rate |
: |
*1 Max. 30 frames/sec. (640 x 480*2, 320 x 240, 192 x144) |
| Security |
: |
User ID/Password, SSL |
| Supported protocols |
: |
IPv4/IPv6 Dual-Stack. IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnP™, SMTP Authentication, RTP, RTSP*3, RTCP, SSL, HTTPS, TLS. IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP*3, RTCP, SSL, HTTPS, TLS. |
| User access limit |
: |
Max. 30 simultaneous accesses (max. 10 accesses in JPEG mode with sound playback or 5 accesses in MPEG-4 mode; with HTTPS communication) (registration: max. 50 users; each user can be assigned User ID/password) |
| Buffered images |
: |
*4 Approx. 350 images (320 x 240) •standard image quality (16KB per image) •with time display •without using SD/SDHC Memory Card |
| Image transfer method |
: |
SMTP*5, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Alarm, timer or motion detection |
Network Camera |
| Zoom |
: |
4.6x zoom (2.3x optical, 2x digital) |
| Viewing angle |
: |
Horizontal--tele: 32° (optical) / 16° (digital), wide: 73°. Vertical----tele: 24° (optical) / 12° (digital), wide: 55°. |
| Pan (horizontal direction) |
: |
-175° up to +175° |
| Tilt (vertical direction) |
: |
0° up to + 82° |
| Revolving speed |
: |
Pan: max. 300°/sec; Tilt: max. 80°/sec |
| Sensor type |
: |
1/3.6 inch new MOS sensor*6, approx. 370,000 pixels |
| Lens focal point |
: |
Fixed (focal range: 0.75 m to ∞) |
| Lens brightness |
: |
F1.9 (wide) – F2.8 (tele) |
| Required light intensity |
: |
2 to 100,000 lux (in Color Night View mode: 0.2 to 100,000 lux) |
Audio |
| Audio communication |
: |
2-Way half duplex |
| Audio compression |
: |
ADPCM 32 kbps |
| Audio bandwidth |
: |
300 Hz – 3.4 kHz |
| Audio input |
: |
Built-in microphone or external microphone input terminal |
| Audio output |
: |
Audio line output terminal for external speaker |
Wireless |
Not Available
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
Input: 2, output: 1 |
| Video output |
: |
Analog composite (NTSC/PAL) |
| Audio output |
: |
3.5 mm stereo mini jack (output is mono) |
| External Microphone Input |
: |
3.5 mm mini jack |
| SD Memory Card slot |
: |
Full size (operation guaranteed for 8 GB and 4 GB SDHC Memory Cards*7, for 2 GB, 1 GB, 512 MB, 256 MB, 128 MB and 64 MB SD Memory Cards) |
General |
| Operating temperature |
: |
-20°C to +50°C (-4°F to +122°F) |
| Operating humidity |
: |
20% to 90% (No Condensation) |
| Dimensions (H x W x D) |
: |
153 x 115 x 153 mm (6 x 4 9/16 x 6 inches) |
| Weight (only the unit) |
: |
690 g (1.52 lb) |
| Power supply (E) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet. AC adaptor: input 120 V AC output 12 V DC |
| Power supply (CE) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet. AC adaptor: input 100-240 V AC output 12 V DC |
| Power supply(US) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet. AC adaptor: input 100-240 V AC output 12 V DC |
| Consumption |
: |
PoE: 4.4 W (max. 7.9 W). AC adaptor: 4.4 W (max. 8.5 W) |
| |
| Other Detail |
: |
Scanning System: Progressive Scan
Audio Reception Method and Decoding: Active X |
