Two-way audio input
|
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
|
IP video input
|
16-ch |
|
Remote connection
|
128 |
|
Incoming bandwidth
|
160Mbps |
|
Outgoing bandwidth
|
160Mbps |
|
HDMI Output
|
1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
|
Recording Resolution
|
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Audio Output
|
1-ch, RCA (Linear, 1kΩ) |
|
Synchronous playback
|
16-ch |
|
VGA Output
|
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
|
Capability
|
8-ch@1080P |
|
Live view / Playback resolution
|
8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
SATA
|
2 SATA interfaces for 2 HDDs |
|
Capacity
|
Up to 6TB capacity for each HDD |
|
Network interface
|
2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
|
Serial Interface
|
RS-232/RS-485 for PTZ, Samsung system keyboard |
|
USB interface
|
Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
|
Alarm Inputs / Output
|
erminal 4 inputs (NO/NC) / Terminal 1 relay outputs (NO), Rating : 24V DC / 1A, 125V AC / 0.5A |
|
Power Supply
|
100~240VAC |
|
Consumption
|
≤ 20W |
|
Working Temperature/Humidity
|
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
|
Chassis
|
19-inch rack-mounted 1.5U chassis |
|
Dimension
|
445 × 390 × 70mm (17.5 ×15.3 × 2.8 inch) |
|
Weight
|
≤ 5 Kg (11 lb) |
