Hikvision DS-7208HUHI-F2/S

Hikvision DS-7208HUHI-F2/S – Turbo HD DVR H.264+ & Dual-stream video compression Support HD-TVI/analog/AHD/IP camera triple hybrid Support both HD-TVI and analog cameras with adaptive access Full channel@5MP resolution non real-time recording HDMI output at up to 4K while VGA output at up to 1920×1080P resolution Long transmission distance over coax cable Support up to 4/8-ch synchronous playback

Hikvision DS-7208HUHI-F2/S – Turbo HD DVR

Jual HIKVISION DS-7208HUHI-F2/S – Turbo HD DVR 5MP dengan harga yang murah dan terjangkau. Turbo HD DVR ini memiliki kompres untuk dual video, support HD-TVI/analog/AHD/IP Camera dan 4/8-ch playback dari recorder. Channel yang penuh hingga 5MP resolusi pada saat tidak live recording. DVR ini dilengkapi juga dengan HDMI output hingga 4k dengan VGA output mencapai 1920 x 1080p

Video Audio/Input
Audio Input	4-ch
Video Compression	H.264,H.264+
Analog and HD-TVI video input	16-ch,BNC interface (1.0Vp-p, 75 Ω)connection
Supported camera types	Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz Support CVBS input
Video Input Interface	BNC (1.0 Vp-p, 75Ω)
Audio Compression	G.711u
Audio Input Interface	4-ch, RCA (2.0 Vp-p, 1 KΩ)
Two-way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)
Video Audio/Output
CVBS Output	1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480
HDMI/VGA Output	HDMI: 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz VGA:1-ch,2K(2560×1440)/60Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz
Recording resolution	Mainstream:5MP/4MP/3Mp/1080p/720p/WD1/4CIF/VGA/CIF Sub-stream:WD1/4CIF/CIF/QVGA/QCIF
Frame Rate	Main stream: 5MP@10fps/4MP@15fps/3MP@15fps/1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps;CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate	32 Kbps-10 Mbps
Stream Type	Video/Video&Audio
Two-way Audio	1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Audio Output	1-ch RCA(Linear, 1kΩ)
Audio Bit Rate	64kbps
Dual Stream	Support
Playback Resolution	5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF
Synchronous Playback	16-ch
Network Management
Remote Connections	128
Network Protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Hard Disk Driver
Interfacce Type	2 SATA Interface
Capacity	Up to 6 TB capacity for each disk
External Interface
Network Interface	1; 10M / 100M / 1000M self-adaptive Ethernet interface
USB Interface	2 USB 2.0 Interface on the front panel& 1 USB 3.0 Interface on the rear panel
Alarm Input	16-ch
Alarm Output	4-ch
General
Power Supply	12V DC
Consumption	≤ 25W(without hard disks)
Working Temperature	-10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
Working Humidity	10% to 90%
Chassis	380mm 1U chassis
Dimensions	380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
Weight	≤2kg(4.4lb)
