PoE Switch
|
Port |
8 100M Ethernet Ports 2 1000M Ethernet Ports 2 1000M SFP Optical Multiplex Ports 1 Console Port |
Backplane Capacity |
64Gbps |
Switching Bandwith |
32Gbps |
Forwarding |
4.2Mpps |
MAC Table |
8K |
Vide Buffering |
64MB |
STP |
IEEE 802.1D STP IEEE 802.1w RSTP IEEE 802.1s MSTP |
VLAN |
Port-based VLAN 802.1Q VLAN GVRP |
VLAN No |
4K (any division) |
QinQ |
Support |
QoS |
Support |
Flow Control |
Backpressure is adopted for half-duplex, while IEEE802.3x is adopted for full-duplex |
Multicast |
IGMP Snooping |
Network Management |
SNMP, Telnet, RMON, CLI, support multiple SNMP network management software |
Network Security |
IEEE 802.1x Port access control IP ACL, MAC ACL and VLAN ACL DHCP snooping DAI and static/dynamic ARP prevention RADIUS |
Dimensions |
340mm×250mm×44mm (13.39”×9.84”×1.73”) |
Power Source |
110-240VAC (self-adaptive), 47-63Hz, 1A/230V PoE/PoE+ power supply |
Power Consumptions |
Max. 170W (including PoE power supply) , support 802.3af power supply on 8 ports or 802.3at power supply on 5 ports |
Indicator |
Power indicator, system indicator, connection/data forwarding indicator, 10/100M indicator |
Environment |
Working temperature: 0 °C ~55 °C (32 °F ~ 131 °F) Humidity: 0-90% (no condensation) |
SFP modules |
HK-1.25G-20-1550: 1000M SFP module, TX1550nm/RX1310nm, LC, single-mode single-fiber, 20km HK-155M-20-1550: 100M SFP module, TX1550nm/RX1310nm, LC, single-mode single-fiber, 20km |
