Image Sensor
|
1/2.8" Progressive Scan CMOS |
Effective Pixels
|
1920(H) ×1080(V) |
Min.Illumination
|
Color: 0.05 Lux@(F1.6, AGC On) ; B/W: 0.01Lux@(F1.6, AGC On) ; 0 lux with IR |
White Balance
|
Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
AGC
|
Auto / Manua |
S/N RATIO
|
≥ 52dB |
Digital Noise Reduction
|
3D DNR |
Backlight Compensation
|
HLC/BLC |
Wide Dynamic Range
|
Digital WDR |
Shutter speed
|
1/1~ 1/10,000s |
Day/Night
|
IR Cut Filter |
Digital Zoom
|
16X |
Focus mode
|
Auto / Semiautomatic / Manual |
Privasi masking
|
2 privacy masks programmable |
Focal Lenght (Zoom Ratio)
|
2.8 ~ 12mm, 4X |
Zoom Speed
|
Approx.1s (Optical Wide-Tele) |
Angle of View
|
115-33.8 degree (Wide-Tele) |
Min. working distance
|
10 ~1500mm (Wide-Tele) |
Aperture range
|
F1.6 ~ F3.5 |
Pan / Tilt Range
|
Pan: 360° endless; Tilt: -10° ~ 90°(Auto Flip) |
Pan / Tiltr speed
|
Pan manual speed: 0.1° ~160°/s, Pan preset speed: 160°/s Tilt manual speed: 0.1°~120°/s, Tilt preset speed: 120°/s |
Proportional zoom
|
Rotation speed can be adjusted automatically according to zoom multiples |
Number of preset
|
256 |
Patrol
|
8 patrols, up to 32 presets per patrol |
Park action
|
Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan |
Power-off memory
|
Support |
PTZ position display
|
Support |
Preset freezing
|
Support |
Scheduled task
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan/Dome reboot/Self-test action/Alarm output |
Video Output
|
1.0V[p-p] / 75Ω, PAL or NTSC composite, BNC |
Audio Input
|
1 Mic in/Line in interface, Line input: 2 ~ 2.4V[p-p]; output impedance: 1KΩ, ±10% |
Audio Output
|
1 Audio output interface, Line level, impedance: 600Ω |
IR distance
|
Up to 30m |
IR intensity
|
Automatically adjusted, depending on the zoom ratio |
Ethernet
|
10Base-T / 100Base-TX, RJ45 connector |
Max. Resolution
|
1920×1080 |
Frame Rate
|
50Hz: 25 fps (1920×1080), 25 fps (1280×720); 60Hz: 30 fps (1920×1080), 30 fps (1280×720) |
Image compression
|
H.264/MJPEG |
Audio Compression
|
G.711u /G.711a /G.726 /MP2L2 |
Protocol
|
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP,IGMP, ICMP, DHCP, PPPoE |
Simultaneous live view
|
Up to 6 |
Stream
|
Dual streams |
SD memory card
|
Built-in micro SD card slot, up to 32GB |
User/Host Leve
|
Up to 32 users, 3 Levels: Administrator, Operator, User |
Security measures
|
User authentication (ID and PW), Host authentication (MAC address), IP address filtering |
Application Programming Interface
|
Open-ended API, support Onvif, PSIA and CGI |
Web Browser
|
IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+ |
Power
|
24VAC/PoE+(802.3at), Max 20W |
Working temperature
|
-30°C ~ 65°C (-22°F ~ 149°F) |
Humidity
|
90% or less |
Protection level
|
l IP66 (outdoor model); TVS 4,000V lightning protection, surge protection and voltage transient protection |
Dimension
|
Φ155×235mm (Φ6.10”×9.25” |
Weight
|
Approx. 2Kg (4.41Ibs) |
Mount option (for outdoor model)
|
Long-arm wall mount: DS-1601ZJ; Corner mount: DS-1601ZJ-corner; Pole Mount: DS-1601ZJ-pole; Power box mount:DS-1634ZJ |
